Lexus LX J200 (2007-2012) right front door control switch assembly Wiring diagrams
This page contains all the electrical diagrams for the component. right front door control switch assembly, in which he is found in the car Lexus LX J200 (2007-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right front door control switch assembly (1 of 3)
BLK WIRE
BLU WIRE
BRN WIRE
DOOR 1 FUSE
DOOR 2 FUSE
DOOR CONTROL SWITCH
DRIVER'S DOOR
ECU- IG 1 FUSE BATB
ECU-IG 2 FUSE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
HOT AT ALL TIMES
HOT W/ IG 1 RELAY ENERGIZED
HOT W/ IG 2 RELAY ENERGIZED
LEFT COWL SIDE J/B
LEFT FRONT DOOR LOCK ASSEMBLY (DRIVER'S DOOR)
LH FR DOOR FUSE
LOCK
LOCK KEY
LSSR
LSWD
LSWP LSWR
LT GRN WIRE
MAIN BODY ECU
MASTER SWITCH ASSEMBLY
MULTIPLEX NETWORK
RED WIRE
RIGHT FRONT DOOR CONTROL SWITCH ASSEMBLY
UNLOCK
UNLOCK KEY
WHT/BLK WIRE
YEL WIRE
Go to component -> Anti-theft circuit (1 of 6) -> RIGHT FRONT DOOR CONTROL SWITCH ASSEMBLY
Wiring diagram right front door control switch assembly (2 of 3)
