Lexus LX J200 (2007-2012) red Wiring diagrams
This page contains all the electrical diagrams for the component. red, in which he is found in the car Lexus LX J200 (2007-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram red (111 of 113)
+B IG+
1 2 3 4 5 6 7 8 9 10 +1 +2
1 2 3 4 5 6 7 8 9 10 11 12 AUTO
1 3 4 ES MPX SIG
36 35 CANH CANL CAN
AUTO OFF MIST
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
CANL CANH
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ECU- IG 1 FUSE
ECU-IG 2 FUSE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
ES +SM WIG
FUSE
GRN WIRE
HIGH LOW
HIGH LOW INT
HOT AT ALL TIMES
HOT IN ON OR START
HOT IN ON OR START LEFT COWL WIPER FUSE SIDE J/B (LEFT END OF DASH)
LT GRN WIRE
MET FUSE
MIST
OFF MIST
OVERHEAD MODULE (CENTER FRONT OF ROOF)
POWER SUPPLY CIRCUIT
RAIN SENSOR (FORWARD OF MOON ROOF)
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
VIO WIRE
WASHER LEVEL SENSOR
WASHER SWITCH
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WASHER MOTOR, PUMP ASSEMBLY (WASHER FLUID RESERVOIR)
WINDSHIELD WIPER ECU (RIGHT END OF DASH)
WINDSHIELD WIPER MOTOR (LEFT REAR OF ENGINE COMPT)
WINDSHIELD WIPER SWITCH ASSEMBLY
WIPER SWITCH HIGH LOW AUTO OFF
WSH FUSE
Go to component -> Front wiper/washer circuit -> RED WIRE
Wiring diagram red (112 of 113)
1 2 3 4 IG
AUTO HEAD TAIL OFF
BLK WIRE
BLU WIRE
ECU- IG 1 FUSE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
H-LP CLN FUSE
HEADLIGHT CLEANER CONTROL RELAY, MOTOR (LEFT SIDE OF ENGINE COMPT)
HEADLIGHT CLEANER SWITCH OUTER MIRROR SWITCH ASSEMBLY
HOT AT ALL TIMES
HOT IN ON OR START
HRLY HEAD
LEFT COWL SIDE J/B (LEFT END OF DASH)
LIGHT CONTROL SWITCH HEADLIGHT DIMMER SWITCH ASSEMBLY
LT GRN WIRE
MAIN BODY ECU
RED WIRE
RED/BLK WIRE
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
Go to component -> Headlamp washer circuit -> RED WIRE
Wiring diagram red (113 of 113)
14 13 5 11 12 18 3 2 1 4 7 BECU SIG WRSW MPX+ MPX- WRIN
BLK WIRE
BLK/ WHT WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
ECU-IG 4 FUSE
GRN WIRE
HOT AT ALL TIMES ENGINE ROOM R/B (LEFT SIDE OF FUSE ENGINE COMPT)
HOT IN ON OR START
LEFT COWL SIDE J/B (LEFT END OF DASH)
LT GRN WIRE
MULTIPLEX NETWORK BODY ECU 2 (RIGHT "D" PILLAR)
ON+WASHER
REAR WIPER MOTOR (CENTER OF REAR DOOR)
REAR WIPER/ WASHER SWITCH
RED WIRE
RED/WHT WIRE
RIGHT COWL SIDE J/B (RIGHT END OF DASH)
RR WIPER FUSE
RWLM RWSM WRLO GND
WASH OFF LO HI
WHT/BLK WIRE
WINDSHIELD WASHER MOTOR, PUMP ASSEMBLY (WASHER FLUID RESERVOIR)
WINDSHIELD WIPER SWITCH ASSEMBLY
Go to component -> Rear wiper/washer circuit -> RED WIRE
