Lexus LX J200 (2007-2012) occupant detection ecu Wiring diagram
This page shows the only wiring diagram for the component.occupant detection ecu, which is found in the car Lexus LX J200 (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram occupant detection ecu (1 of 1)
BLU WIRE
BRN WIRE
CENTER AIR BAG SENSOR ASSEMBLY
CURTAIN AIR BAG CUTOFF SWITCH
DCM (TELEMATICS TRANSCEIVER)
DISPLAY, NAVIGATION MODULE DISPLAY
ENGINE SWITCH
FROM GROUND
FROM JUNCTION
FUEL PUMP CONTROL ECU ASSEMBLY
JUNCTION
LEFT COWL SIDE J/B (LEFT END OF DASH)
LEFT FRONT POWER SEAT CONTROL ECU, SWITCH
LEFT FRONT POWER SEAT SWITCH ASSEMBLY
LEFT FRONT SEAT CLIMATE CONTROL ECU
LEFT FRONT SEAT HEATER ASSEMBLY
LEFT FRONT SEAT INNER BELT ASSEMBLY
LEFT REAR 1 POWER SEAT SWITCH
LEFT REAR DOOR JUNCTION LOCK CONNECTOR ASSEMBLY
LEFT REAR LIGHT ASSEMBLY
LEFT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY
LEFT REAR SEAT HEATER
LICENSE CENTER PLATE STOP LIGHT LIGHT ASSEMBLY ASSEMBLY
MAIN BODY ECU
OCCUPANT DETECTION ECU
PARKING ASSIST ECU
POWER SLIDE BACK DOOR WARNING BUZZER
RADIO RECEIVER ASSEMBLY
REAR WINDOW RIGHT DEFOGGER REAR (BACK LIGHT DOOR ASSEMBLY GLASS)
REAR WIPER MOTOR ASSEMBLY
SEAT VARIABLE CUSHION SWITCH
STEERING LOCK ACTUATOR ASSEMBLY
STEREO COMPONENT AMPLIFIER ASSEMBLY
TRAILER SOCKET
W/ CLIMATE CONTROL SEAT
W/O CLIMATE CONTROL SEAT
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (5 of 6) -> OCCUPANT DETECTION ECU
