Lexus LX J200 (2007-2012) headlight cleaner switch outer mirror switch assembly Wiring diagram
This page shows the only wiring diagram for the component.headlight cleaner switch outer mirror switch assembly, which is found in the car Lexus LX J200 (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram headlight cleaner switch outer mirror switch assembly (1 of 1)
1 2 3 4 IG
AUTO HEAD TAIL OFF
BLK WIRE
BLU WIRE
ECU- IG 1 FUSE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
H-LP CLN FUSE
HEADLIGHT CLEANER CONTROL RELAY, MOTOR (LEFT SIDE OF ENGINE COMPT)
HEADLIGHT CLEANER SWITCH OUTER MIRROR SWITCH ASSEMBLY
HOT AT ALL TIMES
HOT IN ON OR START
HRLY HEAD
LEFT COWL SIDE J/B (LEFT END OF DASH)
LIGHT CONTROL SWITCH HEADLIGHT DIMMER SWITCH ASSEMBLY
LT GRN WIRE
MAIN BODY ECU
RED WIRE
RED/BLK WIRE
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
