Lexus LX J200 (2007-2012) blk Wiring diagrams
This page contains all the electrical diagrams for the component. blk, in which he is found in the car Lexus LX J200 (2007-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
blk wiring diagram (101 of 119)
AT P IND
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/RED WIRE
BUZZER
CDL+
CENTER DIFFERENTIAL LOCK SWITCH
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DL LO
ECM (ENGINE CONTROL MODULE)
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
EXI
FOUR WHEEL DRIVE CONTROL ECU (RIGHT END OF DASH)
FUSE
GRN WIRE
GRN/RED WIRE
HOT IN ON OR START
IG GND
INTEGRATION CONTROL, PANEL ASSEMBLY
JUNCTION
JUNCTION CONNECTORS
LEFT COWL SIDE J/B (LEFT END OF DASH)
LOCK IND DIFFERENTIAL CENTER
LT GRN WIRE
MET FUSE
PNK CAN+ CAN- WIRE
PNK WIRE
PNK/BLU WIRE
POWER SUPPLY CIRCUIT IG+ B+
RED WIRE
RED/BLU WIRE
SKID CONTROL ECU W/ ACTUATOR ASSEMBLY (LEFT REAR OF ENGINE COMPT)
TFN
TGND
TRANSFER POSITION SWITCH
TRANSFER SHIFT ACTUATOR (LEFT SIDE OF TRANSMISSION)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
Go to component -> 4wd circuit -> BLK WIRE
blk wiring diagram (102 of 119)
ALT FUSE
ALT-S FUSE
BATTERY
BLK WIRE
BLU WIRE
COMBINATION IGN+ METER ASSEMBLY CHARGE INDICATOR
ENGINE ROOM R/B
GENERATOR ASSEMBLY
GRN WIRE
HOT W/ IG 1 RELAY ENERGIZED LEFT COWL LH-IG FUSE SIDE J/B (LEFT END OF DASH)
HOT W/ IG 2 RELAY ENERGIZED
MET FUSE (LEFT SIDE OF ENGINE COMPT)
RED WIRE
STARTER ASSEMBLY
WHT WIRE
YEL WIRE
Go to component -> Charging circuit -> BLK WIRE
blk wiring diagram (103 of 119)
+B PGND
1 2 3 4 5 6 7 8 9 10 MOR- MOR+ MOL+ MOL-
1 2 3 4 5 6 7 8 CANH CANL COMPUTER DATA LINES SYSTEM
11 25 CAN H CAN L
2 3 4 5 SGND LRDD LRRD IGB
35 36 COMPUTER DATA LINES SYSTEM PCS IND
8 9 13 23 22 10 CAN H CAN L IGB LRRD LRDD SGND
BLK WIRE
BLU WIRE
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISTANCE CONTROL ECU (RIGHT CENTER OF DASH)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM R/B (LEFT SIDE OF FUSE ENGINE COMPT)
IG+ +B POWER SUPPLY CIRCUIT
LEFT FRONT PRE-COLLISION SEAT BELT MOTOR (BASE OF LEFT "B" PILLAR)
LT BLU WIRE
MILLIMETER WAVE RADAR SENSOR (CENTER FRONT OF ENGINE COMPT)
PSB FUSE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RELAY ENERGIZED LEFT COWL SIDE J/B ECU-IG FUSE (LEFT END OF DASH)
RIGHT FRONT PRE-COLLISION SEAT BELT MOTOR (BASE OF RIGHT "B" PILLAR)
SEAT BELT CONTROL ECU (LEFT SIDE OF DASH)
SKID CONTROL ECU W/ ACTUATOR ASSEMBLY (LEFT REAR OF ENGINE COMPT)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Pre-collision circuit -> BLK WIRE
blk wiring diagram (104 of 119)
1 2 3 4 5 6 7 USB USBG VOT+ USBV VOT- VOR- VOR+
28 29 PNK WIRE
AMP 1 FUSE
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRN WIRE
CTR +
DISPLAY, NAVIGATION MODULE DISPLAY
DLC 3 (DATA LINK CONNECTOR) (LEFT SIDE OF DASH)
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START BK/UP LP FUSE
INSTRUMENT CLUSTER SYSTEM
LEFT COWL SIDE J/B (LEFT END OF DASH)
LEFT STEERING SWITCH
LT GRN WIRE
MI+
MIC -
MICROPHONE AMPLIFIER
MO-
NCA WIRE
OFF HOOK
ON HOOK
PARK/ NEUTRAL POSITION SWITCH (RIGHT SIDE OF TRANSMISSION)
PARKING BRAKE SWITCH (BASE OF PARK BRAKE LEVER)
PNK WIRE
RED WIRE
RIGHT STEERING SWITCH
SEEK
SEEK- MODE
SLDI
SLDO
SPIRAL CABLE ASSEMBLY (IN STEERING COLUMN)
STEERING PAD SWITCH ASSEMBLY
STEREO COMPONENT AMPLIFIER (UNDER DRIVER'S SEAT)
SWITCH WIRE
TMUT
VIO WIRE
VOICE
VOL (-)
W/ BLUETOOTH HANDS-FREE SYSTEM
W/ LEXUS ENFORM W/O LEXUS ENFORM
WFL-
WFR-
WHT WIRE
WHT/BLK WIRE
WUI
WUO
YEL WIRE
Go to component -> Radio circuit, without mark levinson (4 of 4) -> BLK WIRE
blk wiring diagram (105 of 119)
10 11 PNK CANH CANL WIRE
15 16 CANN CANP
BKUP LP FUSE
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
ECM (ENGINE CONTROL MODULE) (RIGHT REAR OF ENGINE COMPT)
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT AT ALL TIMES ENGINE STOP ROOM R/B FUSE (LEFT SIDE OF ENGINE COMPT)
JUNCTION
JUNCTION CONNECTOR
MAIN BODY ECU (LEFT END OF DASH)
P DETECTION
PARK/ NEUTRAL POSITION SWITCH (RIGHT SIDE OF TRANSMISSION)
RED WIRE
RELAY ENERGIZED
RELAY ENERGIZED LEFT ECU-IG 1 COWL FUSE SIDE J/B (LEFT END OF DASH)
SHIFT LOCK CONTROL ECU (UNDER CENTER CONSOLE)
SHIFT LOCK SOLENOID
SLS+
STOP LIGHT SWITCH (LEFT SIDE OF DASH)
WHT/BLK WIRE
Go to component -> Shift interlock circuit -> BLK WIRE
blk wiring diagram (106 of 119)
120 16 NSW STAR
BATTERY
BLK WIRE
BLU WIRE
CHARGING CIRCUIT
ECM (ENGINE CONTROL MODULE) (RIGHT REAR OF ENGINE COMPT)
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
FUSE
GRN WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
HOT W/ IG 2 RELAY ENERGIZED
IGN FUSE
MAIN BODY ECU (LEFT END OF DASH)
PARK/ NEUTRAL POSITION SWITCH (RIGHT SIDE OF TRANSMISSION)
RED WIRE
RED/BLK WIRE
SHORT
ST CUT RELAY
ST FUSE
ST RELAY
STARTER ASSEMBLY
STR+
STSW
WHT WIRE
Go to component -> Starting circuit -> BLK WIRE
blk wiring diagram (107 of 119)
1 2 3 4 5 6 7 GND SGND IGE
19 18 SLR+ SLP
5 6 CANH CANL
BLK WIRE
BRN WIRE
CERTIFICATION ECU (LEFT SIDE OF DASH) LIN
COMPUTER DATA LINES SYSTEM
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
ID CODE BOX (LEFT SIDE OF DASH)
IGN FUSE
JUNCTION
LEFT COWL SIDE J/B (LEFT END OF DASH)
LIN
LT BLU WIRE
MAIN BODY ECU (LEFT END OF DASH)
RED WIRE
RELAY ENERGIZED
STEERING LOCK ACTUATOR (ON STEERING COLUMN)
STR LOCK FUSE
WHT/BLK WIRE
Go to component -> Steering column circuit -> BLK WIRE
blk wiring diagram (108 of 119)
-SR -SL +SR +SL
AIR
ARON
BBL+
BBL- BBL+
BCL+
BLK WIRE
BLU WIRE
BRN WIRE
BUCKLE SWITCH
CANL PAON
CENTER AIR BAG SENSOR (CENTER OF DASH)
COMPUTER DATA LINES SYSTEM
DISPLAY, NAVIGATION MODULE DISPLAY
DK DK
DRIVER SIDE SQUIB CIRCUIT
FIRST STEP SECOND STEP
FRONT PASSENGER SIDE SQUIB CIRCUIT SECOND STEP FIRST STEP
GRN WIRE
GRY WIRE
LEFT FRONT PRETENSIONER (BASE OF LEFT "B" PILLAR)
LEFT FRONT SEAT INNER BELT ASSEMBLY (UNDER DRIVER'S SEAT)
LEFT FRONT SIDE AIR BAG SQUIB CIRCUIT (UNDER DRIVER'S SEAT)
LEFT REAR PRETENSIONER (BASE OF LEFT "C" PILLAR)
LOWER 1 INSTRUMENT PANEL AIR BAG ASSEMBLY
LOWER 2 INSTRUMENT PANEL AIR BAG ASSEMBLY
P- P+ D+ D-
P-AB GSW PK+ PK-
PNK RMIL WIRE
PNK WIRE
RED WIRE
RL- RL+
SPIRAL CABLE SUB-ASSEMBLY (IN STEERING COLUMN)
SR-
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/PNK WIRE
YEL/RED WIRE
Go to component -> Supplemental restraint circuit (1 of 3) -> BLK WIRE
blk wiring diagram (109 of 119)
BBR+
BCR+
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
CENTER AIR BAG SENSOR (CENTER OF DASH)
CURTAIN AIR BAG CUTOFF SWITCH
ENGINE ROOM R/B
FSR+ BBR+ BBR- BCR- BCR+ RMSW FSR-
FUSE
GSW
HOT AT ALL TIMES
IGN FUSE
J/C
LEFT COWL SIDE J/B (LEFT END OF DASH)
MET FUSE (LEFT SIDE OF ENGINE COMPT)
PNK WIRE
REAR FLOOR SIDE AIR BAG SENSOR (UNDER REAR SEATS)
REAR SIDE
RED WIRE
RED/BLU WIRE
RELAY ENERGIZED
RIGHT FRONT SIDE AIR BAG SENSOR ASSEMBLY (RIGHT "B" PILLAR)
RIGHT FRONT SIDE AIR BAG SQUIB CIRCUIT (UNDER FRONT PASSENGER'S SEAT)
RIGHT REAR SIDE AIR BAG SENSOR ASSEMBLY (RIGHT QUARTERPANEL)
RIGHT REAR SIDE AIR BAG SQUIB CIRCUIT (UNDER RIGHT REAR SEAT)
SL-
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Supplemental restraint circuit (2 of 3) -> BLK WIRE
blk wiring diagram (110 of 119)
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BRN WIRE
BUCKLE SWITCH
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
GBT
GPS
GRN WIRE
GRY WIRE
GRY/GRN WIRE
GSP SP GND PS VPS GBT IG DIA FSR+ FSR- BSW BGND GPS BT VBT
LT GRN WIRE
OCCUPANT DETECTION ECU (UNDER FRONT PASSENGER'S SEAT)
OCCUPANT DETECTION SENSOR (UNDER FRONT PASSENGER'S SEAT)
PNK WIRE
POWER SUPPLY CIRCUIT
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RIGHT FRONT SEAT INNER BELT ASSEMBLY (UNDER FRONT PASSENGER'S SEAT)
RSCA OFF
SEAT BELT TENSION SENSOR (BASE OF RIGHT "B" PILLAR)
SEAT POSITION SENSOR
SRS IND
VBT
VIO WIRE
VPS
WHT WIRE
Go to component -> Supplemental restraint circuit (3 of 3) -> BLK WIRE
