Lexus LX J200 (2007-2012) auto light control switch lh Wiring diagram

1 2 3 4 5 6 7 8 9 IG LR LL AIR CONDITIONING SYSTEM AUTO LIGHT CONTROL SWITCH LH AUTOMATIC LIGHT CONTROL SENSOR (TOP CENTER OF DASH) BLK WIRE BLU WIRE BRN WIRE CAN (LEFT SIDE OF ENGINE COMPT) CLTB CLTE CLTS COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM DCTY DISPALY, NAVIGATION MODULE DISPALY DOOR 1 FUSE ECU-IG 2 FUSE EL ER ENGINE SWITCH 9 7 13 FUSE GRN WIRE GRY WIRE HAZARD SWITCH HEAD HEADLIGHT DIMMER SWITCH ASSEMBLY HOT AT ALL TIMES HOT W/ ACC RELAY ENERGIZED IND LCTY LEFT COWL SIDE J/B (LEFT END OF DASH) LEFT TURN LH-IG FUSE LIGHT CONTROL RHEOSTAT LT BLU WIRE LT GRN WIRE MAIN BODY ECU OFF OFF TAIL ONE ORG/ WIRE PANEL TAIL FUSE FUSE PARKING PCTY POWER SUPPLY CIRCUIT RCTY RED WIRE RED/BLU WIRE RELAY ENERGIZED RH TURN SIGNAL SWITCH RHEOSTAT RIGHT TURN SHIFT LOCK CONTROL ECU (UNDER CENTER CONSOLE) SIDE MARKER STEP SWIL TAIL TAIL CANCEL SWITCH TAIL IND (CANADA) TAIL RELAY TSL TSR TURN LEFT HEADLIGHT ASSEMBLY TURN RIGHT HEADLIGHT ASSEMBLY TURN SIGNAL FLASHER FLASHER (LEFT END OF DASH) VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
