Lexus LX J200 (2007-2012) 8 7 canl canh Wiring diagram
This page shows the only wiring diagram for the component.8 7 canl canh, which is found in the car Lexus LX J200 (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 8 7 canl canh (1 of 1)
12 6 CANN CANP
15 16 6 5 CANN CANP CANL CANH
8 7 CANL CANH
ASSEMBLY (RIGHT "D" PILLAR)
BLK WIRE
BLU WIRE
BRN WIRE
CANN
CANP
CERTIFICATION ECU (LEFT SIDE OF DASH)
GRN WIRE
GRY WIRE
LEFT FRONT POWER SEAT CONTROL ECU, SWITCH
LEFT QUARTERPANEL)
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU (LEFT END OF DASH)
MPX
MULTIPLEX NETWORK BODY ECU 2 (RIGHT "D" PILLAR)
MULTIPLEX TILT, TELESCOPIC ECU (ON STEERING COLUMN)
OUTER MIRROR CONTROL ECU (DRIVER'S DOOR)
PNK WIRE
POWER BACK DOOR UNIT
RED WIRE
SHORT CONNECTOR
ST-PLUG
SUSPENSION CONTROL ECU
TIRE PRESSURE WARNING ECU (RIGHT QUARTERPANEL)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> High/low bus circuit (2 of 2) -> 8 7 CANL CANH
