Lexus LX J200 (2007-2012) 10 11 pnk canh canl Wiring diagrams
This page contains all the electrical diagrams for the component. 10 11 pnk canh canl, in which he is found in the car Lexus LX J200 (2007-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 10 11 pnk canh canl (1 of 2)
1 2 3 NE NE- VC
10 11 PNK CANH CANL WIRE
11 1 2 10 SGND SCV+ SCB+ SCV-
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/RED WIRE
CANL CANH 35 36
CLEARANCE SONAR IND
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY, NAVIGATION MODULE DISPLAY
ECM (ENGINE CONTROL MODULE) (RIGHT REAR OF ENGINE COMPT)
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
FUSE
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRY WIRE
GVIF
HOT AT ALL TIMES
HOT IN ON OR START
HOT IN ON OR START LEFT COWL SIDE J/B (LEFT END OF DASH) BK/UP LP FUSE
IG+ MASTER IND
LEFT ULTRASONIC SENSOR 2
LEFT ULTRASONIC SENSOR 3 (LEFT SIDE OF REAR BUMPER)
LT GRN WIRE
MET FUSE
NCA WIRE
NE- NE+
PARK/NEUTRAL POSITION SWITCH (RIGHT SIDE OF TRANSMISSION) RB
PNK 21 22 CANH CANL WIRE
PNK WIRE
POWER SUPPLY CIRCUIT
RED WIRE
RED/BLU WIRE
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY (RIGHT DOOR MIRROR)
RIGHT ULTRASONIC SENSOR 2 (RIGHT OUTSIDE CORNER OF REAR BUMPER)
RIGHT ULTRASONIC SENSOR 3 (RIGHT SIDE OF REAR BUMPER)
SIDE TELEVISION CAMERA
TELEVISION DISPLAY ASSEMBLY (W/ REAR SEAT ENTERTAINMENT SYSTEM)
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Parking assistant circuit (2 of 2) -> 10 11 PNK CANH CANL WIRE
Wiring diagram 10 11 pnk canh canl (2 of 2)
10 11 PNK CANH CANL WIRE
15 16 CANN CANP
BKUP LP FUSE
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
ECM (ENGINE CONTROL MODULE) (RIGHT REAR OF ENGINE COMPT)
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HOT AT ALL TIMES ENGINE STOP ROOM R/B FUSE (LEFT SIDE OF ENGINE COMPT)
JUNCTION
JUNCTION CONNECTOR
MAIN BODY ECU (LEFT END OF DASH)
P DETECTION
PARK/ NEUTRAL POSITION SWITCH (RIGHT SIDE OF TRANSMISSION)
RED WIRE
RELAY ENERGIZED
RELAY ENERGIZED LEFT ECU-IG 1 COWL FUSE SIDE J/B (LEFT END OF DASH)
SHIFT LOCK CONTROL ECU (UNDER CENTER CONSOLE)
SHIFT LOCK SOLENOID
SLS+
STOP LIGHT SWITCH (LEFT SIDE OF DASH)
WHT/BLK WIRE
Go to component -> Shift interlock circuit -> 10 11 PNK CANH CANL WIRE
