Lexus LX J100 facelift (2002-2007) tail ind head ind Wiring diagram
This page shows the only wiring diagram for the component.tail ind head ind, which is found in the car Lexus LX J100 facelift (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tail ind head ind (1 of 1)
A/T OIL TEMP IND
ANTI-LOCK BRAKES SYSTEM
AT P IND
BLU WIRE
BRN WIRE
BUZZER
CHARGE IND
COMBINATION METER
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM WARNING SYSTEM
CRUISE IND
DOME FUSE
EC (AT REAR OF RIGHT CYLINDER HEAD)
ECT PWR IND
ELECTRONIC POWER STEERING SYSTEM
ELECTRONIC SUSPENSION SYSTEM
ENGINE CONTROLS SYSTEM
EXCEPT USA USA
EXTERIOR LIGHTS SYSTEM HEADLIGHTS SYSTEM
FUEL GAUGE
FUEL IND
FUSE
GAUGE 2 FUSE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
JUNCTION CONNECTOR 18 (BEHIND RIGHT SIDE OF DASH, NEAR WINDSHIELD)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL) GAUGE 1 FUSE
LT BLU WIRE
MAINT REQD IND (USA)
MET FUSE
NAVIGATION SYSTEM
OFF
OIL PRESSURE GAUGE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
SEAT BELT IND
SPEEDOMETER
SRS IND
SUPPLEMENTAL RESTRAINTS SYSTEM
TACHOMETER
TAIL IND HEAD IND
TEMP GAUGE
TO COMBINATION METER (DIAGRAM 2 OF 2)
TRANSMISSIONS SYSTEM
VEHICLE SPEED SENSOR (COMBINATION METER) (ON LEFT SIDE OF TRANSMISSION)
VOLTMETER
W/O DRL
WARNING SYSTEM
WARNING SYSTEM EXTERIOR LIGHTS SYSTEM
WIPER/WASHER SYSTEM ANTI-LOCK BRAKES SYSTEM
Go to component -> Instrument cluster circuit (1 of 2) -> TAIL IND HEAD IND
