Lexus LX J100 facelift (2002-2007) swhr hl swvr vl vc vsrl hsrl m+l mhl mvl Wiring diagram
This page shows the only wiring diagram for the component.swhr hl swvr vl vc vsrl hsrl m+l mhl mvl, which is found in the car Lexus LX J100 facelift (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram swhr hl swvr vl vc vsrl hsrl m+l mhl mvl (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 +B
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BODY ECU RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
CENTER AIR BAG SENSOR ASSEMBLY (UNDER FRONT OF CENTER CONSOLE)
DCTY
DEFOGGER SYSTEM
DOOR FUSE
DRIVING POSITION MEMORY SWITCH
FUSE
GAUGE 2 FUSE
GND REV MIRE MIRB RCAN
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
IF (BEHIND LEFT KICK PANEL)
IG (BEHIND LEFT SIDE OF DASH)
J/B 4 (BEHIND UPPER CENTER OF DASH)
J/B 6 (BEHIND RIGHT SIDE OF DASH, NEAR ENGINE CONTROL MODULE)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LEFT REMOTE CONTROL MIRROR GND
LT BLU WIRE
M+ VDD SH SV MR MF
MH MV
PARK/ NEUTRAL POSITION SWITCH (ON RIGHT SIDE OF TRANSMISSION)
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
REMOTE CONTROL MIRROR ECU (BEHIND LEFT SIDE OF DASH)
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
SET-
SIG BECU
SWHR HL SWVR VL VC VSRL HSRL M+L MHL MVL
TIL, TEL FUSE
UNLOCK WARNING SWITCH (BEHIND LEFT SIDE OF DASH)
VSSR HSRR M+R MHR MVR
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Memory systems circuit (1 of 3) -> SWHR HL SWVR VL VC VSRL HSRL M+L MHL MVL
