Lexus LX J100 facelift (2002-2007) sub body ecu Wiring diagrams
This page contains all the electrical diagrams for the component. sub body ecu, in which he is found in the car Lexus LX J100 facelift (2002-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram sub body ecu (1 of 2)
1 RELAY
AHC RELAY
BACK DOOR LOCK MOTOR, BACK DOOR UNLOCK DETECTION SWITCH
BJ (UNDER LEFT FRONT SEAT)
BM (AT LEFT REAR QUARTERPANEL)
DAYTIME RUNNING LIGHT RELAY 3
DOOR CONTROL RECEIVER LEFT BUCKLE SWITCH
EA (AT RIGHT FRONT OF ENGINE COMPT)
EFI OR ECD RELAY STARTER RELAY
ENGINE HOOD COURTESY SWITCH
ENGINE ROOM J/B (ON LEFT INNER FENDER PANEL)
ENGINE ROOM RELAY BLOCK
EXHAUST GAS SENSOR
FROM
GLOVE BOX LIGHT
HEADLIGHT CLEANER CONTROL RELAY
HEADLIGHT CLEANER MOTOR
HTR RELAY
JUNCTION CONNECTOR
LEFT FRONT FOG LIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT HEADLIGHT (HIGH)
LEFT HEADLIGHT (LOW)
LEFT LICENSE PLATE LIGHT HIGH MOUNTED STOP LIGHT REAR WIPER MOTOR
LEFT PARKING LIGHT
LEFT POWER QUARTER WINDOW SWITCH
LEFT REAR COMBINATION LIGHT
LEFT REAR DOOR LOCK MOTOR, LEFT REAR DOOR UNLOCK DETECTION SWITCH
LT BLU WIRE
LUGGAGE COMPARTMENT POWER OUTLET REAR WINDOW DEFOGGER
NIGHT VIEW SWITCH
PRESSURE SWITCH
RHEOSTAT
RIGHT FRONT FOG LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT HEADLIGHT (HIGH)
RIGHT HEADLIGHT (LOW)
RIGHT LICENSE PLATE LIGHT BACK DOOR COURTESY SWITCH
RIGHT PARKING LIGHT
RIGHT POWER QUARTER WINDOW SWITCH REMOTE CONTROL MIRROR SWITCH
RIGHT REAR COMBINATION LIGHT BACK DOOR KEY UNLOCK, LOCK SWITCH
ROLL SENSING OF CURTAIN SHIELD AIR BAGS CUTOFF SWITCH
SUB BODY ECU
TO GROUND EE (DIAGRAM 1 OF 4)
TO LEFT KICK PANEL J/B (DIAGRAM 1 OF 4)
TO RIGHT KICK PANEL J/B (DIAGRAM 3 OF 4)
W/O DRL
WASHER LEVEL WARNING SWITCH
WHT/BLK WIRE
Go to component -> Ground distribution circuit (2 of 4) -> SUB BODY ECU
Wiring diagram sub body ecu (2 of 2)
A/C LOCK SENSOR, A/C MAGNETIC CLUTCH
BL (UNDER REAR OF RIGHT FRONT SEAT)
BODY ECU
BRN WIRE
CENTER AIR BAG SENSOR ASSEMBLY
CENTER DIFFERENTIAL LOCK DETECTION SWITCH
COMBINATION METER
COMBINATION SWITCH
DATA LINK CONNECTOR 3
EC (AT REAR OF RIGHT CYLINDER HEAD)
ED (AT REAR OF LEFT CYLINDER HEAD)
ENGINE CONTROL MODULE
GATEWAY ECU
HEATED OXYGEN SENSOR (BANK 1 SENSOR 1) SHIELD
HEATED OXYGEN SENSOR (BANK 1 SENSOR 2) SHIELD
HEATED OXYGEN SENSOR (BANK 2 SENSOR 1) SHIELD
HEATED OXYGEN SENSOR (BANK 2 SENSOR 2) SHIELD
IG (BEHIND LEFT SIDE OF DASH)
IGNITION COIL, IGNITER 1
IGNITION COIL, IGNITER 2
IGNITION COIL, IGNITER 3
IGNITION COIL, IGNITER 4
IGNITION COIL, IGNITER 5 IGNITION COIL, IGNITER 6
IGNITION COIL, IGNITER 7
IGNITION COIL, IGNITER 8
IGNITION NOISE FILTER
IH (BEHIND RIGHT SIDE OF DASH)
JUNCTION CONNECTOR
LEFT KICK PANEL J/B
LT BLU WIRE
OIL PRESSURE SENDER SHIELD KNOCK SENSOR 1 SHIELD
RADIO, PLAYER
REAR SEAT AUDIO CONTROLLER
RIGHT KICK PANEL J/B
SEAT ECU
SHIELD
SHIELD SHIELD
STEREO COMPONENT AMPLIFIER
SUB BODY ECU
VEHICLE SPEED SENSOR
WHT/BLK WIRE
Go to component -> Ground distribution circuit (4 of 4) -> SUB BODY ECU
