Lexus LX J100 facelift (2002-2007) rss stp tc ts pkb eng+ Wiring diagram
This page shows the only wiring diagram for the component.rss stp tc ts pkb eng+, which is found in the car Lexus LX J100 facelift (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rss stp tc ts pkb eng+ (1 of 1)
1 2 3 4 5 6 7 8 9 10 WA BZ D/G
ABS IND.
ABS, BA, TRAC, VSC ECU (BEHIND LEFT SIDE OF DASH)
ACTIVE TRAC IND
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAIDED YSS YD
BRAKE IND
BRN WIRE
COMBINATION METER
DATA LINK CONNECTOR (DLC) 1 (RIGHT INNER FENDER PANEL)
DATA LINK CONNECTOR (DLC) 3 (BEHIND LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN)
EC (REAR OF RIGHT CYLINDER HEAD)
EE (AT LEFT SIDE OF ENGINE COMPT)
ELECTRONIC SUSPENSION SYSTEM
ENG
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
EXI VSCW BRL IND WT AHCO VYS
FRO FLO
GRN WIRE
GRN/WHT WIRE
GSS 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
GYAW
GYAW YAW
IND VSC OFF
IND VSC TRAC
INFR
J/B 5 (BEHIND LEFT SIDE OF DASH)
J/B 7 (BEHIND RIGHT SIDE OF DASH)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LT BLU WIRE
NEO
PARKING BRAKE SWITCH (ON BASE OF PARK BRAKE LEVER)
PNK/BLK WIRE
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
RL+ RL- RR+ RR- ENG-
RSS STP TC TS PKB ENG+
SIL
SLIP IND
TRAC IND
TRANSMISSIONS SYSTEM
TRC+
USA
VIO/WHT WIRE
VYS
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YAW RATE SENSOR (BELOW CENTER OF DASH, FORWARD OF GEAR SELECTOR)
YEL WIRE
YEL/GRN WIRE
Go to component -> Anti-lock brakes circuit (3 of 3) -> RSS STP TC TS PKB ENG+
