Lexus LX J100 facelift (2002-2007) rsca off ind Wiring diagrams
This page contains all the electrical diagrams for the component. rsca off ind, in which he is found in the car Lexus LX J100 facelift (2002-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rsca off ind (1 of 2)
ABS IND.
BEAM IND
BLK WIRE
BLU WIRE
BODY ECU (AT LEFT KICK PANEL)
BRAKE IND
BRN WIRE
CENTER DIFF LOCK IND
COMBINATION METER
DOOR IND
EC (AT REAR OF RIGHT CYLINDER HEAD)
ENGINE ROOM J/B (ON LEFT INNER FENDER PANEL)
FROM COMBINATION METER (DIAGRAM 1 OF 2)
FUEL SENDER (IN FUEL TANK)
GRN WIRE
GRN/ YEL WIRE
HEAD LH LWR FUSE
HEAD RH UPR FUSE
HOT W/ HEAD HI RELAY ENERGIZED
HOT W/ HEAD RELAY ENERGIZED
HOT W/ TAIL RELAY ENERGIZED
JUNCTION CONNECTOR 17 (BEHIND RIGHT SIDE OF DASH, NEAR WINDSHIELD)
JUNCTION CONNECTOR 19 (BEHIND RIGHT SIDE OF DASH)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LEFT TURN IND
LT BLU WIRE
MALFUNCTION INDICATOR LAMP
NCA WIRE
NIGHT VIEW IND
OIL PRESSURE SENDER (ON LOWER LEFT FRONT SIDE OF ENGINE) HEAT WIRE
PANEL FUSE
PARKING BRAKE SWITCH (ON BASE OF PARK BRAKE LEVER)
REAR LIGHT IND
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT TURN IND
RSCA OFF IND
SLIP IND
TRAC IND ACTIVE TRAC IND (USA) (EXCEPT USA)
VGRS IND
VSC OFF IND
VSC TRAC IND
W/O DRL
WASHER IND
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster circuit (2 of 2) -> RSCA OFF IND
Wiring diagram rsca off ind (2 of 2)
AIR BAG IND (SRS)
BJ (UNDER LEFT FRONT SEAT)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BODY ECU (AT LEFT KICK PANEL)
COMBINATION METER
CURTAIN SHIELD AIR BAGS CUTOFF SWITCH (ROLL SENSING)
DATA LINK CONNECTOR (DLC) 3 (RIGHT OF STEERING COLUMN)
DBKL
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
FPS
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
J/B 4 (BEHIND UPPER CENTER OF DASH)
J/B 7 (BEHIND RIGHT SIDE OF DASH)
J/C 19 (BEHIND RIGHT SIDE OF DASH)
J/C 21 (BEHIND UPPER RIGHT SIDE OF DASH)
J/C 23 (AT LEFT REAR WHEELWELL)
J/C 4 (BEHIND UPPER LEFT SIDE OF DASH)
KICK PANEL)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LT BLU WIRE
LT GRN/BLK WIRE
OPTION CONNECTOR (MAYDAY ECU)
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
PNK/BLU WIRE
RED WIRE
RIGHT KICK PANEL J/B (AT RIGHT
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
RSCA OFF IND
SEAT POSITION SENSOR
SOLID STATE
SSL+ ESL SSL-
TILT, TELESCOPIC ECU (BEHIND LEFT SIDE OF DASH)
VIO WIRE
VIO/WHT WIRE
VUPL
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/PNK WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Supplemental restraints circuit (2 of 2) -> RSCA OFF IND
