Lexus LX J100 facelift (2002-2007) rly ill- Wiring diagram
This page shows the only wiring diagram for the component.rly ill-, which is found in the car Lexus LX J100 facelift (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rly ill- (1 of 1)
+B IG VMC BLWC 2 3 4 5 6 7 8 9 10
1 2 10 FRCLK FRCSD FRCID
11 12 13 14 15 16 17 18 19 20 21 22 MCH MHH HRC HRH VMH BLWH
22 18 11 12 15 17 IG
A/C AMPLIFIER (AT RIGHT SIDE OF CARGO AREA)
A/C CONTROL ASSEMBLY
A/C FUSE
B+ GND
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
CID CSD CLKF
COOL
FCIN BLIN FTIN HIIN
FUSE
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/GRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IF (BEHIND LEFT KICK PANEL)
IG+ 2 3 4 5 6 7 8 9 10 11 12
J/B 4 (BEHIND UPPER CENTER OF DASH)
JUNCTION CONNECTOR 14 (BEHIND RIGHT CENTER OF DASH, NEAR WINDSHIELD)
JUNCTION CONNECTOR 24, 27 (AT RIGHT REAR WHEELWELL)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LT BLU WIRE
LT GRN WIRE
LT GRN/RED WIRE
M-COOL
M-HOT
NCA WIRE
PT GND VZ
REAR AIR MIX CONTROL SERVO MOTOR (BELOW REAR OF CENTER CONSOLE)
REAR COOLER RELAY (ON RIGHT REAR CORNER OF VEHICLE, IN CARGO AREA)
REAR EVAPORATOR TEMPERATURE SENSOR (ON REAR HEATER- A/C UNIT)
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
RLY ILL-
RRMGV
SGND
TPH TEC TINH SG ILL+1
TR TSET
W/O NAVIGATION W/ NAVIGATION
WARM
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Automatic a/c circuit, rear (2 of 2) -> RLY ILL-
