Lexus LX J100 facelift (2002-2007) oil pressure sender shield knock sensor 1 shield Wiring diagram
This page shows the only wiring diagram for the component.oil pressure sender shield knock sensor 1 shield, which is found in the car Lexus LX J100 facelift (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram oil pressure sender shield knock sensor 1 shield (1 of 1)
A/C LOCK SENSOR, A/C MAGNETIC CLUTCH
BL (UNDER REAR OF RIGHT FRONT SEAT)
BODY ECU
BRN WIRE
CENTER AIR BAG SENSOR ASSEMBLY
CENTER DIFFERENTIAL LOCK DETECTION SWITCH
COMBINATION METER
COMBINATION SWITCH
DATA LINK CONNECTOR 3
EC (AT REAR OF RIGHT CYLINDER HEAD)
ED (AT REAR OF LEFT CYLINDER HEAD)
ENGINE CONTROL MODULE
GATEWAY ECU
HEATED OXYGEN SENSOR (BANK 1 SENSOR 1) SHIELD
HEATED OXYGEN SENSOR (BANK 1 SENSOR 2) SHIELD
HEATED OXYGEN SENSOR (BANK 2 SENSOR 1) SHIELD
HEATED OXYGEN SENSOR (BANK 2 SENSOR 2) SHIELD
IG (BEHIND LEFT SIDE OF DASH)
IGNITION COIL, IGNITER 1
IGNITION COIL, IGNITER 2
IGNITION COIL, IGNITER 3
IGNITION COIL, IGNITER 4
IGNITION COIL, IGNITER 5 IGNITION COIL, IGNITER 6
IGNITION COIL, IGNITER 7
IGNITION COIL, IGNITER 8
IGNITION NOISE FILTER
IH (BEHIND RIGHT SIDE OF DASH)
JUNCTION CONNECTOR
LEFT KICK PANEL J/B
LT BLU WIRE
OIL PRESSURE SENDER SHIELD KNOCK SENSOR 1 SHIELD
RADIO, PLAYER
REAR SEAT AUDIO CONTROLLER
RIGHT KICK PANEL J/B
SEAT ECU
SHIELD
SHIELD SHIELD
STEREO COMPONENT AMPLIFIER
SUB BODY ECU
VEHICLE SPEED SENSOR
WHT/BLK WIRE
Go to component -> Ground distribution circuit (4 of 4) -> OIL PRESSURE SENDER SHIELD KNOCK SENSOR 1 SHIELD
