Lexus LX J100 facelift (2002-2007) memory systems interior lights system Wiring diagram
This page shows the only wiring diagram for the component.memory systems interior lights system, which is found in the car Lexus LX J100 facelift (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram memory systems interior lights system (1 of 1)
24 5 15 19 ACT- LSR
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BODY ECU
BZR TRLY
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
DBKL
DOOR FUSE
DOOR LOCKS SYSTEM
DOOR LOCKS SYSTEM COMPUTER DATA LINES SYSTEM
DRL MM
ELECTRONIC SUSPENSION SYSTEM
FUSE
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/BLU WIRE
GRY/RED WIRE
HEADLIGHTS SYSTEM MEMORY SYSTEMS
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
IDLE UP FUSE
IF (BEHIND LEFT KICK PANEL)
IG (BEHIND LEFT SIDE OF DASH)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LMRY
LSWP
LT BLU WIRE
MEMORY SYSTEMS
MEMORY SYSTEMS INTERIOR LIGHTS SYSTEM
PCYL DCYL DEF IDL
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
SIG
SPD HAZ
VIO WIRE
WARNING SYSTEM STARTING/CHARGING SYSTEM ENGINE CONTROLS SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Body control modules circuit (1 of 2) -> MEMORY SYSTEMS INTERIOR LIGHTS SYSTEM
