Lexus LX J100 facelift (2002-2007) lh seat fuse Wiring diagram

A/C FUSE AHC IG FUSE FUSE AIR CONDITIONING SYSTEM ANTI-LOCK BRAKES, INSTRUMENT CLUSTER SYSTEMS BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BM (AT LEFT REAR QUARTERPANEL) BODY ECU CIG FUSE DEFOG FUSE DEFOG RELAY DEFOGGER SYSTEM DOOR FUSE DOOR LOCKS, ANTI-THEFT, POWER WINDOWS SYSTEMS ELECTRONIC POWER STEERING SYSTEM ELECTRONIC SUSPENSION SYSTEM ENGINE CONTROLS SYSTEM FROM DOOR FUSE (DIAGRAM 2 OF 3) FROM ENGINE ROOM J/B (DIAGRAM 1 OF 3) FROM FUSIBLE LINK BLOCK (DIAGRAM 1 OF 3) FRONT POWER OUTLET FUSE FUSE (DIAGRAM 2 OF 3) GAUGE 1 FUSE GRN/RED WIRE GRY WIRE IDLE UP FUSE IGNITION SWITCH J/C 14 (BEHIND RIGHT CENTER OF DASH, NEAR WINDSHIELD) CIGARETTE LIGHTER LEFT KICK PANEL J/B (AT LEFT KICK PANEL) LH SEAT FUSE LOCK LOCK OFF LOCK LOCK OFF OFF LT BLU WIRE LT GRN WIRE LUGGAGE COMPARTMENT POWER OUTLET MIRRORS SYSTEM INSTRUMENT CLUSTER, WARNING, NAVIGATION, ENGINE CONTROLS SYSTEMS MIRRORS SYSTEM NAVIGATION, SOUND SYSTEMS MIRRORS SYSTEM POWER ANTENNA SYSTEM NAVIGATION, SHIFT INTERLOCK SYSTEMS OBD 2 FUSE OFF POWER TOPS SYSTEM NAVIGATION SYSTEM POWER TOPS, MIRRORS SYSTEMS PWR OUTLET FUSE RED/BLU WIRE RELAY RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL) RR WIPER FUSE RUN WIRE SEATS SYSTEM SEATS SYSTEM DEFOGGER SYSTEM SIG STOP FUSE FUSE SUN ROOF FUSE AHC B FUSE FUSE TO ENGINE ROOM J/B (DIAGRAM TO J/B 7 (DIAGRAM 3 OF 3) TO J/C 8 (DIAGRAM 3 OF 3) TO RIGHT KICK PANEL J/B (DIAGRAM 3 OF 3) WARNING, AIR CONDITIONING SYSTEMS WHT WIRE WHT/BLK WIRE WHT/RED WIRE WIPER/WASHER, BODY COMPUTER SYSTEMS BODY COMPUTER SYSTEM YEL/RED WIRE
