Lexus LX J100 facelift (2002-2007) left upper head fuse Wiring diagram
This page shows the only wiring diagram for the component.left upper head fuse, which is found in the car Lexus LX J100 facelift (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left upper head fuse (1 of 1)
BLK/ WHT WIRE
COMBINATION METER
DAYTIME RUNNING LIGHT RELAY 3 (AT RIGHT SIDE OF ENGINE COMPT)
EA (AT RIGHT FRONT OF ENGINE COMPT)
ENGINE ROOM J/B (ON LEFT INNER FENDER LEFT LOWER HEAD FUSE PANEL)
ENGINE ROOM J/B (ON LEFT INNER FENDER PANEL)
FUSE
HEAD HI RELAY
HEAD RELAY
HOT AT ALL TIMES
INDICATOR HIGH BEAM
JUNCTION CONNECTOR 20 (BEHIND RIGHT SIDE OF DASH)
LEFT HEADLIGHT (HIGH)
LEFT HEADLIGHT (LOW)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LEFT UPPER HEAD FUSE
LT BLU WIRE
PARKING BRAKE SWITCH (ON BASE OF PARK BRAKE LEVER)
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT HEADLIGHT (HIGH)
RIGHT HEADLIGHT (LOW)
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
RIGHT LOWER HEAD FUSE
RIGHT UPPER HEAD FUSE
WHT/BLK WIRE
WHT/RED WIRE
Go to component -> Headlights circuit (2 of 2) -> LEFT UPPER HEAD FUSE
