Lexus LX J100 facelift (2002-2007) hot w/ head hi relay energized Wiring diagram
This page shows the only wiring diagram for the component.hot w/ head hi relay energized, which is found in the car Lexus LX J100 facelift (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot w/ head hi relay energized (1 of 1)
ABS IND.
BEAM IND
BLK WIRE
BLU WIRE
BODY ECU (AT LEFT KICK PANEL)
BRAKE IND
BRN WIRE
CENTER DIFF LOCK IND
COMBINATION METER
DOOR IND
EC (AT REAR OF RIGHT CYLINDER HEAD)
ENGINE ROOM J/B (ON LEFT INNER FENDER PANEL)
FROM COMBINATION METER (DIAGRAM 1 OF 2)
FUEL SENDER (IN FUEL TANK)
GRN WIRE
GRN/ YEL WIRE
HEAD LH LWR FUSE
HEAD RH UPR FUSE
HOT W/ HEAD HI RELAY ENERGIZED
HOT W/ HEAD RELAY ENERGIZED
HOT W/ TAIL RELAY ENERGIZED
JUNCTION CONNECTOR 17 (BEHIND RIGHT SIDE OF DASH, NEAR WINDSHIELD)
JUNCTION CONNECTOR 19 (BEHIND RIGHT SIDE OF DASH)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LEFT TURN IND
LT BLU WIRE
MALFUNCTION INDICATOR LAMP
NCA WIRE
NIGHT VIEW IND
OIL PRESSURE SENDER (ON LOWER LEFT FRONT SIDE OF ENGINE) HEAT WIRE
PANEL FUSE
PARKING BRAKE SWITCH (ON BASE OF PARK BRAKE LEVER)
REAR LIGHT IND
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT TURN IND
RSCA OFF IND
SLIP IND
TRAC IND ACTIVE TRAC IND (USA) (EXCEPT USA)
VGRS IND
VSC OFF IND
VSC TRAC IND
W/O DRL
WASHER IND
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster circuit (2 of 2) -> HOT W/ HEAD HI RELAY ENERGIZED
