Lexus LX J100 facelift (2002-2007) front power outlet Wiring diagrams
This page contains all the electrical diagrams for the component. front power outlet, in which he is found in the car Lexus LX J100 facelift (2002-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram front power outlet (1 of 2)
A/C CONTROL ASSEMBLY
ABS, BA, TRAC, VSC ACTUATOR
ABS, BA, TRAC, VSC ECU
AIR VENT MODE CONTROL SERVO MOTOR
AUTO ANTENNA CONTROL RELAY
AUTO WIPER ECU
BLU WIRE
BODY ECU
CENTER CLUSTER INTEGRATION PANEL
CIGARETTE LIGHTER
DAMPING MODE SELECT SWITCH, HEIGHT CONTROL SWITCH
DATA LINK CONNECTOR 3
DEFOG RELAY 2 RELAY RELAY
DRIVING POSITION MEMORY SWITCH
EE (AT LEFT SIDE OF ENGINE COMPT)
ELECTRONICALLY CONTROLLED TRANSMISSION PATTERN SELECT SWITCH
ENGINE CONTROL MODULE
FROM JUNCTION CONNECTOR FROM ENGINE ROOM J/B (DIAGRAM 2 OF 4)
FROM LEFT KICK PANEL J/B (DIAGRAM 1 OF 4)
FRONT INTERIOR LIGHT, REAR PERSONAL LIGHT
FRONT PERSONAL LIGHT
FRONT POWER OUTLET
FUEL PUMP
IF (BEHIND LEFT KICK PANEL)
INNER MIRROR
J/B 4 (BEHIND UPPER CENTER OF DASH)
J/B OVERHEAD SHIELD
JUNCTION CONNECTOR
KEY INTERLOCK SOLENOID
LEFT DOOR KEY LOCK/ UNLOCK SWITCH
LEFT FRONT DOOR LOCK MOTOR, LEFT FRONT DOOR UNLOCK DETECTION SWITCH
LEFT KICK PANEL J/B
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LEFT REAR POWER WINDOW CONTROL SWITCH
LEFT REMOTE CONTROL MIRROR
LEFT VANITY LIGHT
LT BLU WIRE
MOON ROOF CONTROL ECU
MOON ROOF CONTROL SWITCH
MULTI-DISPLAY
NIGHT VIEW ECU
OVERHEAD J/B
POWER WINDOW MASTER SWITCH
REAR HEATER POWER TRANSISTOR
REMOTE CONTROL MIRROR ECU
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
RIGHT VANITY LIGHT
SEAT ECU
SHIFT LOCK CONTROL ECU TRANSPONDER KEY COMPUTER
STEERING SENSOR
SUSPENSION CONTROL ECU
THEFT DETERRENT ECU RAIN SENSOR
TO GROUND BJ (DIAGRAM 2 OF 4)
TO LEFT KICK PANEL J/B (DIAGRAM 1 OF 4)
UNLOCK WARNING SWITCH
VGRS ECU
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (1 of 4) -> FRONT POWER OUTLET
Wiring diagram front power outlet (2 of 2)
A/C FUSE
AHC IG FUSE FUSE
AIR CONDITIONING SYSTEM
ANTI-LOCK BRAKES, INSTRUMENT CLUSTER SYSTEMS
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BM (AT LEFT REAR QUARTERPANEL)
BODY ECU
CIG FUSE
DEFOG FUSE
DEFOG RELAY
DEFOGGER SYSTEM
DOOR FUSE
DOOR LOCKS, ANTI-THEFT, POWER WINDOWS SYSTEMS
ELECTRONIC POWER STEERING SYSTEM
ELECTRONIC SUSPENSION SYSTEM
ENGINE CONTROLS SYSTEM
FROM DOOR FUSE (DIAGRAM 2 OF 3)
FROM ENGINE ROOM J/B (DIAGRAM 1 OF 3)
FROM FUSIBLE LINK BLOCK (DIAGRAM 1 OF 3)
FRONT POWER OUTLET
FUSE
FUSE (DIAGRAM 2 OF 3)
GAUGE 1 FUSE
GRN/RED WIRE
GRY WIRE
IDLE UP FUSE
IGNITION SWITCH
J/C 14 (BEHIND RIGHT CENTER OF DASH, NEAR WINDSHIELD) CIGARETTE LIGHTER
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LH SEAT FUSE
LOCK LOCK OFF
LOCK LOCK OFF OFF
LT BLU WIRE
LT GRN WIRE
LUGGAGE COMPARTMENT POWER OUTLET
MIRRORS SYSTEM INSTRUMENT CLUSTER, WARNING, NAVIGATION, ENGINE CONTROLS SYSTEMS
MIRRORS SYSTEM NAVIGATION, SOUND SYSTEMS
MIRRORS SYSTEM POWER ANTENNA SYSTEM
NAVIGATION, SHIFT INTERLOCK SYSTEMS
OBD 2 FUSE
OFF
POWER TOPS SYSTEM NAVIGATION SYSTEM
POWER TOPS, MIRRORS SYSTEMS
PWR OUTLET FUSE
RED/BLU WIRE
RELAY
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
RR WIPER FUSE
RUN WIRE
SEATS SYSTEM
SEATS SYSTEM DEFOGGER SYSTEM
SIG
STOP FUSE FUSE
SUN ROOF FUSE AHC B FUSE FUSE
TO ENGINE ROOM J/B (DIAGRAM
TO J/B 7 (DIAGRAM 3 OF 3)
TO J/C 8 (DIAGRAM 3 OF 3)
TO RIGHT KICK PANEL J/B (DIAGRAM 3 OF 3)
WARNING, AIR CONDITIONING SYSTEMS
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
WIPER/WASHER, BODY COMPUTER SYSTEMS BODY COMPUTER SYSTEM
YEL/RED WIRE
Go to component -> Power distribution circuit (2 of 3) -> FRONT POWER OUTLET
