Lexus LX J100 facelift (2002-2007) engine control module (behind right Wiring diagram
This page shows the only wiring diagram for the component.engine control module (behind right, which is found in the car Lexus LX J100 facelift (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine control module (behind right (1 of 1)
A/C CONTROL ASSEMBLY (W/ NAVIGATION SYSTEM)
AUTO WIPER ECU (BEHIND LEFT SIDE OF DASH)
BLK WIRE
BODY ECU (AT LEFT KICK PANEL)
BUS -
CENTER AIR BAG SENSOR ASSEMBLY (UNDER FRONT OF CENTER CONSOLE)
COMBINATION METER
ENGINE CONTROL MODULE (BEHIND RIGHT
GATEWAY ECU (W/ NAVIGATION SYSTEM) (BEHIND CENTER OF DASH)
J/B 4 (BEHIND UPPER CENTER OF DASH)
J/C 18 (BEHIND RIGHT SIDE OF DASH, NEAR WINDSHIELD)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LEFT REAR POWER WINDOW CONTROL SWITCH
LT BLU WIRE
MAYDAY ECU
MPX
PNK/BLK WIRE
POWER SEAT ECU (BELOW DRIVER'S SEAT)
POWER WINDOW MASTER SWITCH
RAIN SENSOR (ON ROOF, IN FRONT OF MOON ROOF)
RED/YEL WIRE
REMOTE CONTROL MIRROR ECU (BEHIND LEFT SIDE OF DASH)
RIGHT FRONT POWER WINDOW CONTROL SWITCH
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
RIGHT REAR POWER WINDOW CONTROL SWITCH
SIDE OF DASH)
SUB BODY ECU (AT LEFT REAR QUARTERPANEL) MPX+
THEFT DETERRENT ECU (BEHIND CENTER OF DASH)
TILT, TELESCOPIC ECU (BEHIND LEFT SIDE OF DASH)
WHT WIRE
Go to component -> High/low bus circuit -> ENGINE CONTROL MODULE (BEHIND RIGHT
