Lexus LX J100 facelift (2002-2007) efio efii Wiring diagram
This page shows the only wiring diagram for the component.efio efii, which is found in the car Lexus LX J100 facelift (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram efio efii (1 of 1)
+B IG IND CTY
27 26 IMI IMO
7 6 5 4 3 2 1 GND
BLK WIRE
BLK/RED WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
EFIO EFII
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
FUSE
GRN WIRE
GRN/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IF (BEHIND LEFT KICK PANEL)
IGN FUSE
II (BEHIND RIGHT SIDE OF DASH)
J/B 4 (BEHIND UPPER CENTER OF DASH)
J/B 7 (BEHIND RIGHT SIDE OF DASH)
J/C 16 (BEHIND RIGHT CENTER OF DASH, NEAR WINDSHIELD)
KSW CODE TXCT AGND GND
LEFT FRONT DOOR COURTESY SWITCH (ON LEFT "B" PILLAR)
LEFT KICK PANEL J/B
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LP SCTY
LT BLU WIRE
MULTI-DISPLAY
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
TRANSPONDER KEY AMPLIFIER (BEHIND LEFT CENTER OF DASH)
TXCT CODE
UNLOCK WARNING SWITCH (BEHIND LEFT SIDE OF DASH)
VIO WIRE
VIO/GRN WIRE
VIO/WHT WIRE
W/ NAVIGATION SYSTEM
W/O NAVIGATION SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Immobilizer circuit -> EFIO EFII
