Lexus LX J100 facelift (2002-2007) ahc main relay Wiring diagram
This page shows the only wiring diagram for the component.ahc main relay, which is found in the car Lexus LX J100 facelift (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ahc main relay (1 of 1)
3 RELAY
A/C AMPLIFIER
A/C AMPLIFIER SHIELD
A/C CONTROL ASSEMBLY
AHC MAIN RELAY
AHC PUMP MOTOR
AUTO ANTENNA MOTOR
AUTO ANTENNA MOTOR SHIELDS TELESCOPIC MOTOR SHIELD
BK (UNDER FRONT OF RIGHT FRONT SEAT)
BLOWER MOTOR CONTROLLER VGRS ECU
CENTER DIFFERENTIAL LOCK CONTROL RELAY
COMBINATION SWITCH
DVD AUTOMATIC CHANGER GATEWAY ECU
EB (AT RIGHT SIDE OF ENGINE COMPT)
FROM JUNCTION CONNECTOR
FRONT PASSENGER'S POWER SEAT CONTROL SWITCH
FRONT PASSENGER'S SEAT CUSHION HEATER
FRONT PASSENGER'S SEAT HEATER SWITCH DRIVER'S SEAT HEATER SWITCH
FRONT PASSENGER'S SEAT LUMBAR SUPPORT CONTROL SWITCH
FRONT WIPER MOTOR DATA LINK CONNECTOR 1
J/B 4 (BEHIND UPPER CENTER OF DASH)
JUNCTION CONNECTOR
LT BLU WIRE
MULTI-DISPLAY
NAVIGATION ECU
REAR CONSOLE POWER OUTLET
REAR COOLER POWER TRANSISTOR
RIGHT BUCKLE SWITCH
RIGHT DOOR KEY LOCK/ UNLOCK SWITCH
RIGHT FRONT DOOR LOCK MOTOR, RIGHT FRONT DOOR UNLOCK DETECTION SWITCH
RIGHT FRONT POWER WINDOW CONTROL SWITCH RIGHT DOOR LOCK CONTROL SWITCH
RIGHT KICK PANEL J/B
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
RIGHT REAR COMBINATION LIGHT
RIGHT REMOTE CONTROL MIRROR TOWING BRAKE CONTROLLER
SHIELD
SUSPENSION CONTROL ECU
TELEVISION CAMERA ECU
TILT MOTOR SHIELD TILT, TELESCOPIC ECU
TO RIGHT KICK PANEL J/B (DIAGRAM 3 OF 4)
TO SPLICE
TOWING CONVERTER RELAY
TRAILER SOCKET
TURN SIGNAL FLASHER
W/ NAVIGATION
W/O NAVIGATION
W/O NAVIGATION W/ NAVIGATION
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (3 of 4) -> AHC MAIN RELAY
