Lexus LX J100 facelift (2002-2007) a/c control assembly antu antd Wiring diagram
This page shows the only wiring diagram for the component.a/c control assembly antu antd, which is found in the car Lexus LX J100 facelift (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram a/c control assembly antu antd (1 of 1)
A/C CONTROL ASSEMBLY ANTU ANTD
ANT
AUTO ANTENNA CONTROL RELAY (BEHIND GLOVE BOX)
AUTO ANTENNA MOTOR (AT RIGHT REAR OF ENGINE COMPT)
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
CENTER CLUSTER S-ANTU INTEGRATION PANEL
DOWN
FUSE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
J/B 4 (BEHIND UPPER CENTER OF DASH)
J/C 14 (BEHIND RIGHT CENTER OF DASH, NEAR WINDSHIELD)
J/C 22 (BEHIND UPPER RIGHT SIDE OF DASH)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL) IF
NCA WIRE
RADIO, PLAYER ANT
RED WIRE
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
RIGHT KICK PANEL J/B RADIO FUSE (AT RIGHT KICK PANEL)
S-ANTD
SDWN
SGND
SIG
SUP
VCC
W/ NAVIGATION
W/O NAVIGATION
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power antenna circuit -> A/C CONTROL ASSEMBLY ANTU ANTD
