Lexus LX J100 facelift (2002-2007) 9 10 3 2 4 14 16 7 20 cpub bdr keye gnd kl kul lswe Wiring diagram

9 10 3 2 4 14 16 7 20 CPUB BDR KEYE GND KL KUL LSWE BACK DOOR KEY LOCK, UNLOCK SWITCH BJ (UNDER LEFT FRONT SEAT) BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE DOME FUSE ENGINE ROOM J/B (ON LEFT INNER FENDER PANEL) FUSE GENERATOR GRN/BLK WIRE GRN/ORG WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN ON OR START J/B 6 (BEHIND RIGHT SIDE OF DASH, NEAR ENGINE CONTROL MODULE) LEFT DOOR KEY LOCK, UNLOCK SWITCH (IN LEFT FRONT DOOR) LEFT FRONT DOOR COURTESY SWITCH (ON LEFT "B" PILLAR) LEFT KICK PANEL J/B (AT LEFT KICK PANEL) LEFT KICK PANEL J/B (AT LEFT KICK PANEL) IF LEFT REAR DOOR COURTESY SWITCH (ON LEFT ``C" PILLAR) LT BLU WIRE PARK/ NEUTRAL POSITION SWITCH (ON RIGHT SIDE OF TRANSMISSION) POWER WINDOW MASTER SWITCH RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RIGHT DOOR KEY LOCK, UNLOCK SWITCH (IN RIGHT FRONT DOOR) RIGHT DOOR LOCK CONTROL SWITCH RIGHT FRONT DOOR COURTESY SWITCH (ON RIGHT "B" PILLAR) RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL) RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL) II RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL) P/W (FL) FUSE RIGHT REAR DOOR COURTESY SWITCH (ON RIGHT ``C" PILLAR) SECURITY FUSE SIG WHT WIRE WHT/BLK WIRE
