Lexus LX J100 facelift (2002-2007) 20 18 5 19 tc sil tach wfse Wiring diagram

12 1 14 TC TS SIL 19 12 3 TC SIL LA 20 18 5 19 TC SIL TACH WFSE 3 11 12 D/G TC TS A/B ABS, BA, TRAC, VSC ECU (BEHIND LEFT SIDE OF DASH) BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BODY ECU (AT LEFT KICK PANEL) BRN WIRE CENTER AIR BAG SENSOR ASSEMBLY (UNDER FRONT OF CENTER CONSOLE) COMBINATION METER DATA LINK CONNECTOR (DLC) 1 (ON RIGHT INNER FENDER PANEL) DATA LINK CONNECTOR (DLC) 3 (BEHIND LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN) EB (AT RIGHT SIDE OF ENGINE COMPT) ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) ENGINE ROOM R/B (INTEGRAL TO ENGINE ROOM JUNCTION BLOCK) C/OPN RELAY HOT AT ALL TIMES HOT IN ON OR START IGN FUSE J/B 4 (BEHIND UPPER CENTER OF DASH) J/B 7 (BEHIND RIGHT SIDE OF DASH) LEFT KICK PANEL J/B (AT LEFT KICK PANEL) LEFT KICK PANEL J/B (AT LEFT KICK PANEL) IF LT BLU WIRE MULTI-DISPLAY OBD 2 FUSE PNK/BLK WIRE REV RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL) SIL SUSPENSION CONTROL ECU (BEHIND LEFT CENTER OF DASH) TAC THEFT DETERRENT ECU (BEHIND CENTER OF DASH) TRANSPONDER KEY COMPUTER (BEHIND CENTER OF DASH) VGRS ECU (BEHIND LEFT SIDE OF DASH) VIO/WHT WIRE WFSE WHT WIRE WHT/BLK WIRE WHT/RED WIRE
