Lexus LX J100 facelift (2002-2007) 19 12 3 tc sil la Wiring diagram
This page shows the only wiring diagram for the component.19 12 3 tc sil la, which is found in the car Lexus LX J100 facelift (2002-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 19 12 3 tc sil la (1 of 1)
12 1 14 TC TS SIL
19 12 3 TC SIL LA
20 18 5 19 TC SIL TACH WFSE
3 11 12 D/G TC TS
A/B
ABS, BA, TRAC, VSC ECU (BEHIND LEFT SIDE OF DASH)
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BODY ECU (AT LEFT KICK PANEL)
BRN WIRE
CENTER AIR BAG SENSOR ASSEMBLY (UNDER FRONT OF CENTER CONSOLE)
COMBINATION METER
DATA LINK CONNECTOR (DLC) 1 (ON RIGHT INNER FENDER PANEL)
DATA LINK CONNECTOR (DLC) 3 (BEHIND LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN)
EB (AT RIGHT SIDE OF ENGINE COMPT)
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
ENGINE ROOM R/B (INTEGRAL TO ENGINE ROOM JUNCTION BLOCK) C/OPN RELAY
HOT AT ALL TIMES
HOT IN ON OR START
IGN FUSE
J/B 4 (BEHIND UPPER CENTER OF DASH)
J/B 7 (BEHIND RIGHT SIDE OF DASH)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL) IF
LT BLU WIRE
MULTI-DISPLAY
OBD 2 FUSE
PNK/BLK WIRE
REV
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
SIL
SUSPENSION CONTROL ECU (BEHIND LEFT CENTER OF DASH)
TAC
THEFT DETERRENT ECU (BEHIND CENTER OF DASH)
TRANSPONDER KEY COMPUTER (BEHIND CENTER OF DASH)
VGRS ECU (BEHIND LEFT SIDE OF DASH)
VIO/WHT WIRE
WFSE
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
Go to component -> Data link connector circuit -> 19 12 3 TC SIL LA
