Lexus LX J100 facelift (2002-2007) 1 2 3 4 5 6 7 8 ig lr ll +b el er gnd ehw Wiring diagram

1 2 3 4 5 6 7 8 IG LR LL +B EL ER GND EHW 3 16 HZR GND A/C CONTROL ASSEMBLY (W/O NAVIGATION SYSTEM) BJ (UNDER LEFT FRONT SEAT) BLK WIRE BLK/WHT WIRE BM (AT LEFT REAR QUARTERPANEL) BRN WIRE CENTER CLUSTER INTEGRATION PANEL (W/ NAVIGATION SYSTEM) COMBINATION METER RIGHT TURN IND COMBINATION SWITCH EC (AT REAR OF RIGHT CYLINDER HEAD) ENGINE ROOM J/B (ON LEFT INNER FENDER PANEL) FUSE GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRN/YEL WIRE HAZ- TRN FUSE HOT AT ALL TIMES HOT IN ON OR START HZR J/B 6 (BEHIND RIGHT SIDE OF DASH, NEAR ENGINE CONTROL MODULE) JUNCTION CONNECTOR 14 (BEHIND LEFT CENTER OF DASH, NEAR WINDSHIELD) JUNCTION CONNECTOR 7 (BEHIND LEFT SIDE OF DASH, FORWARD OF INSTRUMENT CLUSTER) LEFT KICK PANEL J/B (AT LEFT KICK PANEL) LEFT KICK PANEL J/B (AT LEFT KICK PANEL) STOP FUSE LEFT REAR COMBINATION LIGHT HIGH MOUNTED STOP LIGHT LEFT TURN IND LT BLU WIRE RED WIRE RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL) STOP STOP LIGHT STOP LIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) STOP LIGHT TURN SIGNAL LIGHT TAIL- LIGHT TOWING BRAKE CONTROLLER (BEHIND LEFT SIDE OF DASH) TOWING CONVERTER RELAY (ON LEFT REAR OF CARGO AREA) TURN SIGNAL FLASHER (BEHIND LEFT SIDE OF DASH) TURN SIGNAL SWITCH RH WHT WIRE WHT/BLK WIRE YEL WIRE
