Instrument illumination circuit for Lexus LX J100 (1998-2002)

1 2 3 4 5 IG 6 7 8 TR A/C AMPLIFIER A/T SHIFT LEVER ASHTRAY BLK WIRE BRN WIRE CENTER ECU CIGARETTE LIGHTER COMBINATION METER DAMPING MODE SELECT SWITCH, HEIGHT CONTROL SWITCH DRIVER'S SEAT HEATER SWITCH ELECTRONICALLY CONTROLLED TRANSMISSION PATTERN SELECT SWITCH GAUGE FUSE GLOVE BOX LIGHT GRN WIRE GRN/BLK WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN START OR RUN JUNCTION CONNECTOR J/C 1 (LEFT END OF DASH) JUNCTION CONNECTOR J/C 14 (UPPER CENTER OF DASH) JUNCTION CONNECTOR J/C 18 (UPPER CENTER OF DASH) JUNCTION CONNECTOR J/C 20 (UPPER RIGHT END OF DASH) JUNCTION CONNECTOR J/C 23 JUNCTION CONNECTOR J/C 24 (UPPER RIGHT END OF DASH) JUNCTION CONNECTOR J/C 35 (TOP OF LEFT REAR WHEELWELL) JUNCTION CONNECTOR J/C 37 (BEHIND LEFT REAR WHEELWELL) JUNCTION CONNECTOR J/C 38 (RIGHT REAR WHEELWELL) JUNCTION CONNECTOR J/C 39 (BEHIND RIGHT REAR WHEEL- WELL) LEFT KICK PANEL J/B (AT LEFT KICK PANEL) LEFT POWER QUARTER WINDOW SWITCH LT BLU WIRE PASSENGER'S SEAT HEATER SWITCH RADIO, PLAYER REAR A/C CONTROL SWITCH RED/BLU WIRE REMOTE CONTROL MIRROR SWITCH RHEOSTAT RIGHT POWER QUARTER WINDOW SWITCH TAIL FUSE TAIL RELAY WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE
