Lexus LX J100 (1998-2002) transmission system cruise control system transmission system Wiring diagram
This page shows the only wiring diagram for the component.transmission system cruise control system transmission system, which is found in the car Lexus LX J100 (1998-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transmission system cruise control system transmission system (1 of 1)
A/T OIL TEMP IND
ANTI-LOCK BRAKE SYSTEM
AT-P
BLU WIRE
BRAKE IND
BRN WIRE
CENTER DIFF IND
CHARGE IND
COMBINATION METER
CRUISE IND
DOOR IND
ECT PWR IND
ECU-B FUSE
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS SYSTEM, TRANSMISSION CONTROLS SYSTEM
FUEL GAUGE
FUEL IND
GAUGE FUSE
GRN WIRE
GRN/RED WIRE
HI OFF
HIGH BEAM IND
HOT AT ALL TIMES
HOT IN ON OR START
IGN FUSE
INTERIOR LIGHTS SYSTEM ANTI-LOCK BRAKE SYSTEM
INTERIOR LIGHTS SYSTEM STARTING/CHARGING SYSTEM
J/C 14 (CENTER OF DASH)
J/C 17 (UPPER RIGHT SIDE OF DASH) J/C 20 (UPPER RIGHT SIDE OF DASH)
J/C 26 (UPPER RIGHT SIDE OF DASH)
J/C 3 (UPPER LEFT SIDE OF DASH)
J/C 6 (UPPER LEFT SIDE OF DASH)
LEFT BUCKLE SWITCH
LEFT KICK PANEL J/B
LEFT TURN IND
LT BLU WIRE
LT LT
MALFUNCTION IND
O/D OFF IND
OIL PRESSURE GAUGE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RIGHT KICK PANEL J/B
RIGHT TURN IND
SEAT BELT IND
SPEEDOMETER
SRS IND
SUPPLEMENTAL RESTRAINTS SYSTEM
TACHOMETER
TAILLIGHT IND (CANADA)
TO ABS INDICATOR (DIAGRAM 2 OF 2)
TO COMBI- NATION METER (DIAGRAM 2 OF 2)
TRANSMISSION SYSTEM
TRANSMISSION SYSTEM CRUISE CONTROL SYSTEM TRANSMISSION SYSTEM
VEHICLE SPEED SENSOR (LEFT SIDE OF TRANSMISSION)
VOLTMETER
WASHER IND
WATER TEMP GAUGE
WATER TEMPERATURE SENDER (TOP RIGHT SIDE OF ENGINE)
WHT WIRE
WHT/BLK WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> TRANSMISSION SYSTEM CRUISE CONTROL SYSTEM TRANSMISSION SYSTEM
