Lexus LX J100 (1998-2002) rrmgv face b/l foot Wiring diagram

A/C AMPLIFIER (REAR) (ON RIGHT SIDE OF CARGO AREA) A/C CONDENSER FAN MOTOR (IN RIGHT FRONT OF ENGINE COMPT) A/C CONDENSER FAN RELAY (ON LEFT FRONT OF ENGINE COMPARTMENT, NEAR HEADLIGHT) A/C FUSE A/C MAGNETIC CLUTCH, LOCK SENSOR (ON A/C COMPRESSOR) B+ CID CSD CLK LAT GND 18 19 20 21 22 B+ SI GND 3 2 BL (+) BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLOWER MOTOR CONTROLLER (BEHIND LOWER RIGHT SIDE OF DASH) BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BRN/WHT WIRE CDS FAN FUSE CELLULAR PHONES SYSTEM CENTER ECU (BEHIND CENTER OF DASH) CONTROL CIRCUIT DASH HARN, BEHIND COMBINATION METER) DEF DEFOGGER SYSTEM ENGINE ROOM J/B (ON LEFT INNER FENDER PANEL) F/D DEF FRBLW FRHR MGC FACE FOOT FOOT/ DEF FRCLK FRCSD FRLAT FRCID LOCK FUSE GRN WIRE GRN/RED WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START HTR FUSE IGN INSTRUMENT CLUSTER SYSTEM J/C 11 (BEHIND UPPER LEFT CENTER OF DASH) J/C 38 (BEHIND RIGHT REAR WHEELWELL) J/C 39 (BEHIND RIGHT REAR WHEELWELL) SHIELD LEFT KICK PANEL J/B (AT LEFT KICK PANEL) LT GRN WIRE LT GRN/RED WIRE M- M+ MG CLT RELAY MRRHR ORG/ WIRE PNK/BLU WIRE POSITION SWITCHES RDFGR REAR A/C CIRCUIT RED WIRE RED/BLU WIRE RRMGV FACE B/L FOOT SPD ACT TEL IN TW PSW VIO WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/RED WIRE
