Lexus LX J100 (1998-2002) right license plate light Wiring diagrams
This page contains all the electrical diagrams for the component. right license plate light, in which he is found in the car Lexus LX J100 (1998-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right license plate light (1 of 2)
BLK WIRE
BLK/RED WIRE
BLU/BLK WIRE
CANADA
COMBINATION METER
ENGINE ROOM J/B (ON LEFT INNER FENDER PANEL)
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HAZ- TRN FUSE
HAZARD SWITCH (CENTER ECU)
HOT AT ALL TIMES
HOT IN START OR RUN
JUNCTION CONNECTOR J/C 1 (BEHIND LEFT SIDE OF DASH, NEAR STEERING COLUMN)
JUNCTION CONNECTOR J/C 11 (UPPER LEFT CENTER OF DASH)
JUNCTION CONNECTOR J/C 14 (BEHIND UPPER CENTER OF DASH)
JUNCTION CONNECTOR J/C 20 (UPPER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 32 (ABOVE LEFT REAR WHEELWELL)
JUNCTION CONNECTOR J/C 33 (ABOVE LEFT REAR WHEELWELL)
JUNCTION CONNECTOR J/C 34 (ABOVE LEFT REAR WHEELWELL)
JUNCTION CONNECTOR J/C 37 (BEHIND LEFT REAR WHEELWELL)
JUNCTION CONNECTOR J/C 38 (IN BACK DOOR)
JUNCTION CONNECTOR J/C 40 (BEHIND RT RR WHEELWELL)
JUNCTION CONNECTOR J/C 7 (LEFT SIDE OF DASH, FORWARD OF INSTRU- MENT CLUSTER)
JUNCTION CONNECTOR J/C 8 (LEFT SIDE OF DASH, FORWARD OF INSTRUMENT CLUSTER)
LEFT
LEFT FRONT TURN SIGNAL LIGHT
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LEFT KICK PANEL J/B (LEFT KICK PANEL)
LEFT LICENSE PLATE LIGHT (FRONT OF RIGHT FRONT FENDER)
LEFT PARKING, SIDE MARKER LIGHT
LEFT REAR COMBINATION LIGHT (OUTER)
LEFT TURN INDIC
LOCK
LT BLU WIRE
NUMBER 2 FUSE
RIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
RIGHT LICENSE PLATE LIGHT
RIGHT PARKING, SIDE MARKER LIGHT
RIGHT REAR COMBINATION LIGHT (OUTER) LEFT, RIGHT REAR COMBINATION LIGHTS (INNER)
RIGHT TURN INDIC
RUN WIRE
TAIL FUSE
TAIL INDIC (CANADA)
TAIL RELAY
TURN SIGNAL FLASHER (BEHIND LEFT SIDE OF DASH)
TURN TL
WHT WIRE
WHT/BLK WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> RIGHT LICENSE PLATE LIGHT
Wiring diagram right license plate light (2 of 2)
A/C AMPLIFIER
BACK DOOR COURTESY SWITCH LEFT LICENSE PLATE LIGHT
BACK DOOR KEY LOCK, UNLOCK SWITCH RIGHT REAR COMBINATION LIGHT
BACK DOOR UNLOCK MOTOR, UNLOCK DETECTION SWITCH
CARGO COMPARTMENT POWER OUTLET
FROM
FROM CENTER DIFFERENTIAL LOCK CONTROL RELAY (DIAGRAM 2 OF 4)
FROM JUNCTION CONNECTOR J/C 20 (DIAGRAM 3 OF 4)
FUEL PUMP CONTROL ECU
HIGH MOUNTED STOP LIGHT
JUNCTION CONNECTOR J/C 32 (ABOVE LEFT REAR WHEELWELL)
JUNCTION CONNECTOR J/C 39 (IN BACK DOOR)
LEFT FRONT DAMPING FORCE CONTROL ACTUATOR
LEFT REAR COMBINATION LIGHT
LT BLU WIRE
MTR RELAY
PASSENGER'S SEAT HEATER
PASSENGERS POWER SEAT CONTROL SWITCH
REAR COOLER POWER TRANSISTOR
REAR DIFFERENTIAL LOCK CONTROL ECU
REAR DIFFERENTIAL LOCK DETECTION SWITCH
REAR DIFFERENTIAL LOCK MOTOR
REAR WINDOW DEFOGGER
REAR WIPER MOTOR
RIGHT BUCKLE SWITCH
RIGHT DOOR KEY LOCK/ UNLOCK SWITCH
RIGHT DOOR LOCK CONTROL SWITCH
RIGHT FRONT DOOR LOCK MOTOR, DOOR UNLOCK DETECTION SWITCH
RIGHT FRONT POWER WINDOW CONTROL SWITCH
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
RIGHT LICENSE PLATE LIGHT
RIGHT REAR COMBINATION LIGHT
RIGHT REAR DAMPING FORCE CONTROL ACTUATOR
RIGHT REAR DOOR LOCK MOTOR, DOOR UNLOCK DETECTION SWITCH
RIGHT REAR WINDOW CONTROL SWITCH
RIGHT REMOTE CONTROL MIRROR
TELEPHONE TRANSCEIVER/ SPEAKER RELAY
TRAILER SOCKET
WHT/BLK WIRE
Go to component -> Ground distribution circuit (4 of 4) -> RIGHT LICENSE PLATE LIGHT
