Lexus LX J100 (1998-2002) right door lock control switch Wiring diagrams
This page contains all the electrical diagrams for the component. right door lock control switch, in which he is found in the car Lexus LX J100 (1998-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
right door lock control switch wiring diagram (1 of 4)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 GRD
1 7 2 11 9 4 BECU RLCY SIG DLRY TRY GRD
14 1 12 18 6 13 ACY RRCY DURY DISW PISW DDRY
20 11 6 10 7 14 3 9 5 8 4 KSW DKU DKL PKU PKL DCY PCY PML PMU DML DMU
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BZR TRLY
ENGINE ROOM J/B (ON LEFT INNER FENDER PANEL)
FUSE
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/BLU WIRE
HAZ- TRN FUSE
HOT AT ALL TIMES
INSTRUMENT ECU (BEHIND CENTER OF DASH)
JUNCTION CONNECTOR J/C 1 (LEFT END OF DASH)
JUNCTION CONNECTOR J/C 12 (LEFT SIDE OF DASH)
JUNCTION CONNECTOR J/C 14 (BEHIND LEFT CENTER OF DASH)
JUNCTION CONNECTOR J/C 15 (BEHIND LEFT CENTER OF DASH)
JUNCTION CONNECTOR J/C 16 (UPPER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 23 (UPPER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 24 (UPPER RIGHT END OF DASH)
JUNCTION CONNECTOR J/C 25 (UPPER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 3 (LEFT SIDE OF DASH)
JUNCTION CONNECTOR J/C 43 (BEHIND LEFT SIDE OF DASH)
KSW LSWD LSWP IG CTY
LEFT DOOR KEY LOCK/ UNLOCK SWITCH
LEFT DOOR LOCK CONTROL SWITCH (POWER WINDOW MASTER SWITCH)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LSWR
LT BLU WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RIGHT DOOR KEY LOCK/ UNLOCK SWITCH
RIGHT DOOR LOCK CONTROL SWITCH
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
WHT GRN/ WIRE
WHT WIRE
WHT/BLK WIRE
WIRELESS DOOR LOCK BUZZER (IN REAR OF LEFT FRONT FENDER)
WIRELESS DOOR LOCK ECU (BEHIND LEFT OF DASH)
Go to component -> Anti-theft circuit (1 of 3) -> RIGHT DOOR LOCK CONTROL SWITCH
right door lock control switch wiring diagram (2 of 4)
1 11 18 6 15 10 RRCY RRCL DISW PISW FRCL RLCL
7 2 1 8 10 4 RLCY SIG BECU LMRY
BLK RED/ WIRE
BLU/WHT WIRE
BLU/YEL WIRE
GRD
GRN/BLK WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
INSTRUMENT ECU (BEHIND CENTER OF DASH)
JUNCTION CONNECTOR J/C 13 (BEHIND LEFT CENTER OF DASH)
JUNCTION CONNECTOR J/C 14 (LEFT CENTER OF DASH)
JUNCTION CONNECTOR J/C 17 (CENTER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 23 (UPPER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 24 (UPPER RIGHT END OF DASH)
JUNCTION CONNECTOR J/C 26 (UPPER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 6 (UPPER LEFT SIDE OF DASH)
KSW KYIL PKU DKU DKL PKL PCY DCY DML DMU PML PMU FRRM
LEFT DOOR KEY LOCK/ UNLOCK SWITCH
LEFT DOOR LOCK CONTROL SWITCH (POWER WINDOW MASTER SWITCH)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LT BLU WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RIGHT DOOR KEY LOCK/ UNLOCK SWITCH
RIGHT DOOR LOCK CONTROL SWITCH
RIGHT FRONT DOOR COURTESY LIGHT
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
RIGHT REAR DOOR COURTESY LIGHT
RIGHT SIDE STEP LIGHT
WHT/BLK WIRE
WIRELESS DOOR LOCK ECU (BEHIND LEFT OF DASH)
Go to component -> Courtesy lamps circuit (1 of 3) -> RIGHT DOOR LOCK CONTROL SWITCH
right door lock control switch wiring diagram (3 of 4)
A/C AMPLIFIER
BACK DOOR COURTESY SWITCH LEFT LICENSE PLATE LIGHT
BACK DOOR KEY LOCK, UNLOCK SWITCH RIGHT REAR COMBINATION LIGHT
BACK DOOR UNLOCK MOTOR, UNLOCK DETECTION SWITCH
CARGO COMPARTMENT POWER OUTLET
FROM
FROM CENTER DIFFERENTIAL LOCK CONTROL RELAY (DIAGRAM 2 OF 4)
FROM JUNCTION CONNECTOR J/C 20 (DIAGRAM 3 OF 4)
FUEL PUMP CONTROL ECU
HIGH MOUNTED STOP LIGHT
JUNCTION CONNECTOR J/C 32 (ABOVE LEFT REAR WHEELWELL)
JUNCTION CONNECTOR J/C 39 (IN BACK DOOR)
LEFT FRONT DAMPING FORCE CONTROL ACTUATOR
LEFT REAR COMBINATION LIGHT
LT BLU WIRE
MTR RELAY
PASSENGER'S SEAT HEATER
PASSENGERS POWER SEAT CONTROL SWITCH
REAR COOLER POWER TRANSISTOR
REAR DIFFERENTIAL LOCK CONTROL ECU
REAR DIFFERENTIAL LOCK DETECTION SWITCH
REAR DIFFERENTIAL LOCK MOTOR
REAR WINDOW DEFOGGER
REAR WIPER MOTOR
RIGHT BUCKLE SWITCH
RIGHT DOOR KEY LOCK/ UNLOCK SWITCH
RIGHT DOOR LOCK CONTROL SWITCH
RIGHT FRONT DOOR LOCK MOTOR, DOOR UNLOCK DETECTION SWITCH
RIGHT FRONT POWER WINDOW CONTROL SWITCH
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
RIGHT LICENSE PLATE LIGHT
RIGHT REAR COMBINATION LIGHT
RIGHT REAR DAMPING FORCE CONTROL ACTUATOR
RIGHT REAR DOOR LOCK MOTOR, DOOR UNLOCK DETECTION SWITCH
RIGHT REAR WINDOW CONTROL SWITCH
RIGHT REMOTE CONTROL MIRROR
TELEPHONE TRANSCEIVER/ SPEAKER RELAY
TRAILER SOCKET
WHT/BLK WIRE
Go to component -> Ground distribution circuit (4 of 4) -> RIGHT DOOR LOCK CONTROL SWITCH
right door lock control switch wiring diagram (4 of 4)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 GRD
1 7 2 11 9 4 BECU RLCY SIG DLRY TRY GRD
14 1 12 18 6 13 ACY RRCY DURY DISW PISW DDRY
20 11 6 10 7 14 3 9 5 8 4 KSW DKU DKL PKU PKL DCY PCY PML PMU DML DMU
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BZR TRLY
ENGINE ROOM J/B (ON LEFT INNER FENDER PANEL)
FUSE
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/BLU WIRE
HAZ- TRN FUSE
HOT AT ALL TIMES
INSTRUMENT ECU (BEHIND CENTER OF DASH)
JUNCTION CONNECTOR J/C 1 (LEFT END OF DASH)
JUNCTION CONNECTOR J/C 12 (LEFT SIDE OF DASH)
JUNCTION CONNECTOR J/C 14 (BEHIND LEFT CENTER OF DASH)
JUNCTION CONNECTOR J/C 15 (BEHIND LEFT CENTER OF DASH)
JUNCTION CONNECTOR J/C 16 (UPPER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 23 (UPPER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 24 (UPPER RIGHT END OF DASH)
JUNCTION CONNECTOR J/C 25 (UPPER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 3 (LEFT SIDE OF DASH)
JUNCTION CONNECTOR J/C 43 (BEHIND LEFT SIDE OF DASH)
KSW LSWD LSWP IG CTY
LEFT DOOR KEY LOCK/ UNLOCK SWITCH
LEFT DOOR LOCK CONTROL SWITCH (POWER WINDOW MASTER SWITCH)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LSWR
LT BLU WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RIGHT DOOR KEY LOCK/ UNLOCK SWITCH
RIGHT DOOR LOCK CONTROL SWITCH
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
WHT GRN/ WIRE
WHT WIRE
WHT/BLK WIRE
WIRELESS DOOR LOCK BUZZER (IN REAR OF LEFT FRONT FENDER)
WIRELESS DOOR LOCK ECU (BEHIND LEFT OF DASH)
Go to component -> Power door lock circuit (1 of 3) -> RIGHT DOOR LOCK CONTROL SWITCH
