Lexus LX J100 (1998-2002) rh-upr head fuse Wiring diagrams
This page contains all the electrical diagrams for the component. rh-upr head fuse, in which he is found in the car Lexus LX J100 (1998-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
rh-upr head fuse wiring diagram (1 of 2)
+B HI DRL
BATTERY
BLK WIRE
BLK/ORG WIRE
BLU/WHT WIRE
CHG
COMBINATION METER
DAYTIME RUNNING LIGHT RELAY 3 (ON RIGHT FRONT INNER FENDER PANEL)
DIMMER RELAY
E (GRD)
ECU-B FUSE
ENGINE ROOM J/B (ON LEFT INNER FENDER PANEL)
FUSIBLE LINK BLOCK
GAUGE FUSE
HEAD INDIC (USA)
HEAD RELAY
HIGH BEAM INDIC
HOT AT ALL TIMES
HOT IN START OR RUN
JUNCTION CONNECTOR J/C 1
JUNCTION CONNECTOR J/C 20 (BEHIND RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 23 (UPPER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 7 (BEHIND LEFT SIDE OF DASH)
LEFT HIGH BEAM HEADLIGHT
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LEFT KICK PANEL J/B (LEFT KICK PANEL)
LEFT LOW BEAM HEADLIGHT
LH- LWR HEAD FUSE
LH-UPR HEAD FUSE
LT BLU WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RH- LWR HEAD FUSE
RH-UPR HEAD FUSE
RIGHT HIGH BEAM HEADLIGHT
RIGHT LOW BEAM HEADLIGHT
STARTING/ CHARGING SYSTEM
USA
WHT/BLK WIRE
Go to component -> Headlight circuit (2 of 2) -> RH-UPR HEAD FUSE
rh-upr head fuse wiring diagram (2 of 2)
A/C FUSE
ABS 1 FUSE
ABS 2 FUSE FUSE
ABS SOL RELAY
AHC FUSE
AHC RELAY
AIR CONDITIONING SYSTEM
ALT FUSE
ALT-S FUSE J/B 2 FUSE
AM 1 NUM- BER 1 FUSE
AM 1 NUM- BER 2 FUSE
ANTI-THEFT, EXTERIOR LIGHTS SYSTEMS
BATTERY
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
CDS FAN FUSE
COOLING FANS, AIR CONDITIONING SYSTEMS
COOLING FANS, AIR CONDITIONING, WARNING SYSTEMS
CRUISE CONTROL, TRANSMISSIONS, ENGINE CONTROLS SYSTEMS
DIMMER RELAY
EFI OR ECD FUSE
ENGINE ROOM J/B (ON LEFT INNER FENDER PANEL)
FROM ENGINE ROOM J/B (DIAGRAM 1 OF 2)
FUSE
FUSE (1999) (2000- 2001)
FUSIBLE LINK BLOCK
GRN/RED WIRE
GRN/WHT WIRE
HAZ- TRN FUSE
HEAD CLNR FUSE
HEAD RELAY
HEADLIGHTS, INSTRUMENT CLUSTER SYSTEMS
HORN FUSE
HORN RELAY
HTR FUSE
IGN 1 RELAY
IGN 2 RELAY
LH-LWR HEAD FUSE RH-LWR HEAD FUSE
LH-UPR HEAD FUSE
MIR HTR FUSE
MIR HTR RELAY
POWER ANTENNA, SOUND, NAVIGATION SYSTEMS
RADIO FUSE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RELAY
RH-UPR HEAD FUSE
SEAT HTR FUSE
SEATS SYSTEM
STARTER FUSE
STARTER RELAY RELAY
THROTTLE FUSE
TO ENGINE ROOM J/B (DIAGRAM 1 OF 2)
TO IGNITION SWITCH (DIAGRAM 2 OF 2)
TO JUNCTION CONNECTOR J/C 10 (DIAGRAM 2 OF 2)
TO LEFT KICK PANEL J/B (DIAGRAM 2 OF 2)
TO LEFT KICK PANEL J/B (DIAGRAM 2 OF 2) STARTING/ CHARGING SYSTEM
TRAILER TOWING
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
WIPER/ WASHER SYSTEM
YEL/BLK WIRE
Go to component -> Power distribution circuit (1 of 2) -> RH-UPR HEAD FUSE
