Lexus LX J100 (1998-2002) radio, player ant Wiring diagram
This page shows the only wiring diagram for the component.radio, player ant, which is found in the car Lexus LX J100 (1998-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram radio, player ant (1 of 1)
ANT
AUTO ANTENNA CONTROL RELAY (BEHIND GLOVE BOX)
AUTO ANTENNA MOTOR (IN RIGHT REAR OF ENGINE COMPARTMENT)
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRAID
CENTER ECU (BEHIND CENTER OF DASH)
CIG FUSE
DOWN
ECU-IG FUSE
ENGINE ROOM J/B (ON LEFT INNER FENDER PANEL)
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
J/C 30 (RIGHT SIDE OF DASH)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
RADIO FUSE
RADIO, PLAYER ANT
RED WIRE
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
S-ANTD
S-ANTU
SDWN
SGND
SIG
SUP
VCC
W/ NAVIGATION SYSTEM W/O NAVIGATION SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power antenna circuit -> RADIO, PLAYER ANT
