Lexus LX J100 (1998-2002) main daytime running light relay wireless door lock ecu Wiring diagram

ABS SOL RELAY EFI OR ECD RELAY STARTER RELAY AHC RELAY RELAY AHC MAIN RELAY AIR VENT MODE CONTROL SERVO MOTOR AUTO ANTENNA CONTROL RELAY BLOWER MOTOR CONTROLLER CELLULAR PHONE HANDSET CENTER DIFFERENTIAL LOCK CONTROL RELAY CENTER ECU CIGARETTE LIGHTER DAMPING MODE SELECT, HEIGHT CONTROL SWITCH DATA LINK CONNECTOR 3 DRIVER'S SEAT HEATER SWITCH ELECTRONICALLY CONTROLLED TRANSMISSION PATTERN SELECT SWITCH ENGINE CONTROL MODULE ENGINE HOOD COURTESY SWITCH ENGINE ROOM J/B (ON LEFT INNER FENDER PANEL) EXHAUST GAS SENSOR FRONT POWER OUTLET HEADLIGHT CLEANER CONTROL RELAY A/C CONDENSER FAN MOTOR HEADLIGHT CLEANER MOTOR A/C TRIPLE SWITCH IGNITION 1 RELAY IGNITION 2 RELAY JUNCTION CONNECTOR J/C 1 (LEFT SIDE OF DASH) JUNCTION CONNECTOR J/C 11 (UPPER LEFT CENTER OF DASH) KEY INTERLOCK SOLENOID LEFT FRONT FOG LIGHT LEFT FRONT TURN SIGNAL LIGHT LEFT LO BEAM HEADLIGHT LEFT PARKING, SIDE MARKER LIGHT MAIN DAYTIME RUNNING LIGHT RELAY WIRELESS DOOR LOCK ECU O/D MAIN SWITCH PASSENGER'S SEAT HEATER SWITCH POWER OUTLET (REAR CONSOLE BOX) RIGHT FRONT TURN SIGNAL LIGHT RIGHT FRONT FOG LIGHT RIGHT LO BEAM HEADLIGHT DAYTIME RUNNING LIGHT RELAY 3 RIGHT PARKING, SIDE MARKER LIGHT SHIFT LOCK CONTROL ECU SUSPENSION CONTROL ECU TILT, TELESCOPIC ECU TO ABS, BA, TRAC, VSC ECU (DIAGRAM 3 OF 4) TO LEFT KICK PANEL J/B (DIAGRAM 3 OF 4) TO RIGHT KICK PANEL J/B (DIAGRAM 4 OF 4) TURN SIGNAL FLASHER UNLOCK WARNING SWITCH WASHER MOTOR WHT/ BLK WIRE WHT/BLK WIRE
