Lexus LX J100 (1998-2002) luggage compartment power outlet Wiring diagram

AHC-B FUSE FR FOG FUSE AHC-IG FUSE AIR COND- ITIONING SYSTEM BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BLU/YEL WIRE CIGAR FUSE SRS FUSE CIGARETTE LIGHTER DEFOG FUSE STOP FUSE DEFOG RELAY DOME FUSE DOME RELAY ECU-B FUSE ELECTRONIC SUSPENSION SYSTEM FR FOG RELAY FROM ENGINE ROOM J/B (DIAGRAM 1 OF 2) FROM FUSIBLE LINK BLOCK (DIAGRAM 1 OF 2) FROM LEFT KICK PANEL J/B (DIAGRAM 2 OF 2) FRONT POWER OUTLET GARAGE DOOR OPENER CRUISE CONTROL, ENGINE CONTROLS SYSTEM GAUGE FUSE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE IGN FUSE IGNITION SWITCH JUNCTION CONNECTOR J/C 1 (LEFT SIDE OF DASH) LEFT KICK PANEL J/B (AT LEFT KICK PANEL) LOCK LT BLU WIRE LT GRN WIRE LUGGAGE COMPARTMENT POWER OUTLET MIRR FUSE MIRRORS, BODY COMPUTER SYSTEMS POWER FUSE POWER RELAY D/L (U) RELAY D/L (L) RELAY D/L (DU) RELAY PWR OUTLET FUSE ECU-IG FUSE REAR CONSOLE BOX POWER OUTLET RED WIRE RED/BLU WIRE RR A/C FUSE RR HTR FUSE OBD FUSE RR HTR RELAY RUN WIRE STARTING SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM TAIL FUSE TAIL RELAY TO LEFT KICK PANEL J/B (DIAGRAM 2 OF 2) TRANSMISSIONS SYSTEM WIPER/ WASHER, BODY COMPUTER SYSTEMS WHT WIRE WHT/BLK WIRE WHT/RED WIRE WIPER FUSE DIFF FUSE (1999-2000) (2001)
