Lexus LX J100 (1998-2002) left vanity light Wiring diagrams
This page contains all the electrical diagrams for the component. left vanity light, in which he is found in the car Lexus LX J100 (1998-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left vanity light (1 of 2)
BLU/BLK WIRE
BLU/ORG WIRE
DOOR
FRONT INTERIOR LIGHT, REAR PERSONAL LIGHT
FRONT PERSONAL LIGHT
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
IGNITION KEY CYLINDER LIGHT
JUNCTION CONNECTOR J/C 1 (LEFT END OF DASH)
JUNCTION CONNECTOR J/C 3 (UPPER LEFT SIDE OF DASH)
JUNCTION CONNECTOR J/C 4 (UPPER LEFT SIDE OF DASH)
LEFT FRONT DOOR COURTESY LIGHT
LEFT FRONT DOOR LOCK MOTOR, DOOR UNLOCK DETECTION SWITCH
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LEFT KICK PANEL J/B (LEFT KICK PANEL)
LEFT REAR DOOR COURTESY LIGHT
LEFT VANITY LIGHT
LT BLU WIRE
REAR INTERIOR LIGHT
RED WIRE
RED/BLK WIRE
RIGHT FRONT DOOR LOCK MOTOR, DOOR UNLOCK DETECTION SWITCH
RIGHT KICK PANEL J/B (RIGHT KICK PANEL)
RIGHT VANITY LIGHT
UNLOCK WARNING SWITCH
WHT/BLK WIRE
WHT/BLU WIRE
Go to component -> Courtesy lamps circuit (3 of 3) -> LEFT VANITY LIGHT
Wiring diagram left vanity light (2 of 2)
ABS, BA, TRAC, VSC ACTUATOR
ABS, BA, TRAC, VSC ECU
AUTO ANTENNA MOTOR AHC PUMP MOTOR FRONT WIPER MOTOR
BLK/ WHT WIRE
BLU LT WIRE
BRN WIRE
COMBINATION METER
COMBINATION SWITCH
D/L (DU) RELAY
D/L (L) RELAY
D/L (U) RELAY
DRIVING POSITION MEMORY SWITCH
FROM DRIVER'S SEAT HEATER SWITCH (DIAGRAM 2 OF 4)
FROM ENGINE ROOM J/B (DIAGRAM 2 OF 4)
FROM LEFT BUCKLE SWITCH (DIAGRAM 1 OF 4)
FROM LEFT KICK PANEL J/B (DIAGRAM 3 OF 4)
FRONT INTERIOR LIGHT, REAR PERSONAL LIGHT
FRONT PERSONAL LIGHT
GARAGE DOOR OPENER
INNER MIRROR
JUNCTION CONNECTOR J/C 20 (UPPER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 23 (UPPER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 30 (UPPER RIGHT END OF DASH)
JUNCTION CONNECTOR J/C 41 (LEFT SIDE OF DASH)
LEFT DOOR KEY LOCK/ UNLOCK SWITCH
LEFT FRONT DOOR LOCK MOTOR, DOOR UNLOCK DETECTION SWITCH
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LEFT QUARTER POWER WINDOW SWITCH
LEFT REAR DOOR LOCK MOTOR, UNLOCK DETECTION SWITCH
LEFT REAR POWER WINDOW SWITCH
LEFT REMOTE CONTROL MIRROR
LEFT VANITY LIGHT
LT BLU WIRE
MOON ROOF CONTROL ECU
MOON ROOF CONTROL SWITCH
POWER RELAY
POWER WINDOW MASTER SWITCH
REAR HEATER POWER TRANSISTOR
REMOTE CONTROL MIRROR ECU
REMOTE CONTROL MIRROR SWITCH
RHEOSTAT
RIGHT QUARTER POWER WINDOW SWITCH
RIGHT VANITY LIGHT
STEREO COMPONENT AMPLIFIER RADIO, PLAYER
THEFT DETERRENT ECU GLOVE BOX LIGHT
TO LEFT KICK PANEL J/B (DIAGRAM 3 OF 4)
TO RIGHT KICK PANEL J/B (DIAGRAM 4 OF 4)
TO RIGHT KICK PANEL J/B (DIAGRAM 4 OF 4) FROM ENGINE ROOM J/B (DIAGRAM 2 OF 4)
TURN SIGNAL LIGHT SWITCH WIPER, WASHER SWITCH LIGHT CONTROL SWITCH
WHT/BLK WIRE
Go to component -> Ground distribution circuit (3 of 4) -> LEFT VANITY LIGHT
