Lexus LX J100 (1998-2002) left power quarter window switch Wiring diagrams
This page contains all the electrical diagrams for the component. left power quarter window switch, in which he is found in the car Lexus LX J100 (1998-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
left power quarter window switch wiring diagram (1 of 2)
1 2 3 4 5 IG
6 7 8 TR
A/C AMPLIFIER
A/T SHIFT LEVER
ASHTRAY
BLK WIRE
BRN WIRE
CENTER ECU
CIGARETTE LIGHTER
COMBINATION METER
DAMPING MODE SELECT SWITCH, HEIGHT CONTROL SWITCH
DRIVER'S SEAT HEATER SWITCH
ELECTRONICALLY CONTROLLED TRANSMISSION PATTERN SELECT SWITCH
GAUGE FUSE
GLOVE BOX LIGHT
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN START OR RUN
JUNCTION CONNECTOR J/C 1 (LEFT END OF DASH)
JUNCTION CONNECTOR J/C 14 (UPPER CENTER OF DASH)
JUNCTION CONNECTOR J/C 18 (UPPER CENTER OF DASH)
JUNCTION CONNECTOR J/C 20 (UPPER RIGHT END OF DASH)
JUNCTION CONNECTOR J/C 23
JUNCTION CONNECTOR J/C 24 (UPPER RIGHT END OF DASH)
JUNCTION CONNECTOR J/C 35 (TOP OF LEFT REAR WHEELWELL)
JUNCTION CONNECTOR J/C 37 (BEHIND LEFT REAR WHEELWELL)
JUNCTION CONNECTOR J/C 38 (RIGHT REAR WHEELWELL)
JUNCTION CONNECTOR J/C 39 (BEHIND RIGHT REAR WHEEL- WELL)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LEFT POWER QUARTER WINDOW SWITCH
LT BLU WIRE
PASSENGER'S SEAT HEATER SWITCH
RADIO, PLAYER
REAR A/C CONTROL SWITCH
RED/BLU WIRE
REMOTE CONTROL MIRROR SWITCH
RHEOSTAT
RIGHT POWER QUARTER WINDOW SWITCH
TAIL FUSE
TAIL RELAY
WHT/BLK WIRE
WHT/GRN WIRE
WHT/RED WIRE
Go to component -> Instrument illumination circuit -> LEFT POWER QUARTER WINDOW SWITCH
left power quarter window switch wiring diagram (2 of 2)
GAUGE FUSE
HOT IN START OR RUN
JUNCTION CONNECTOR J/C 14 (UPPER CENTER OF DASH)
JUNCTION CONNECTOR J/C 20 (UPPER RIGHT SIDE OF DASH)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LEFT POWER QUARTER WINDOW SWITCH
LEFT POWER VENT WINDOW MOTOR
LT BLU WIRE
PNK WIRE
RED WIRE
RED YEL/ WIRE
RED/BLU WIRE
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
RIGHT POWER QUARTER WINDOW SWITCH
RIGHT POWER VENT WINDOW MOTOR
WHT/BLK WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Rear quarter windows circuit -> LEFT POWER QUARTER WINDOW SWITCH
