Lexus LX J100 (1998-2002) left low beam headlight Wiring diagram
This page shows the only wiring diagram for the component.left low beam headlight, which is found in the car Lexus LX J100 (1998-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left low beam headlight (1 of 1)
+B HI DRL
BATTERY
BLK WIRE
BLK/ORG WIRE
BLU/WHT WIRE
CHG
COMBINATION METER
DAYTIME RUNNING LIGHT RELAY 3 (ON RIGHT FRONT INNER FENDER PANEL)
DIMMER RELAY
E (GRD)
ECU-B FUSE
ENGINE ROOM J/B (ON LEFT INNER FENDER PANEL)
FUSIBLE LINK BLOCK
GAUGE FUSE
HEAD INDIC (USA)
HEAD RELAY
HIGH BEAM INDIC
HOT AT ALL TIMES
HOT IN START OR RUN
JUNCTION CONNECTOR J/C 1
JUNCTION CONNECTOR J/C 20 (BEHIND RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 23 (UPPER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 7 (BEHIND LEFT SIDE OF DASH)
LEFT HIGH BEAM HEADLIGHT
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LEFT KICK PANEL J/B (LEFT KICK PANEL)
LEFT LOW BEAM HEADLIGHT
LH- LWR HEAD FUSE
LH-UPR HEAD FUSE
LT BLU WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RH- LWR HEAD FUSE
RH-UPR HEAD FUSE
RIGHT HIGH BEAM HEADLIGHT
RIGHT LOW BEAM HEADLIGHT
STARTING/ CHARGING SYSTEM
USA
WHT/BLK WIRE
Go to component -> Headlight circuit (2 of 2) -> LEFT LOW BEAM HEADLIGHT
