Lexus LX J100 (1998-2002) frrm pcy dmu pmu dkl pkl dml pml pku dku Wiring diagram
This page shows the only wiring diagram for the component.frrm pcy dmu pmu dkl pkl dml pml pku dku, which is found in the car Lexus LX J100 (1998-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram frrm pcy dmu pmu dkl pkl dml pml pku dku (1 of 1)
2000- 2001
BECU SIG WLRY
BLK WIRE
BLK/WHT WIRE
BLU WIRE
DATA LINK CONNECTOR 1 (ON RIGHT INNER FENDER PANEL)
DATA LINK CONNECTOR 3 (BEHIND LEFT SIDE OF DASH)
DISW
DLRY LS/M
DOOR LOCKS SYSTEM
DOOR LOCKS SYSTEM INTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM
DOOR LOCKS SYSTEM MEMORY SYSTEMS MEMORY SYSTEMS
DOOR LOCKS SYSTEM WIPER/WASHER SYSTEM
ECU-B FUSE
ECU-IG FUSE
EXTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM
FRRM PCY DMU PMU DKL PKL DML PML PKU DKU
HOT AT ALL TIMES
HOT IN RUN
HW DCY HRY
INDP
INSTRUMENT ECU (BEHIND CENTER OF DASH)
INTERIOR LIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM
INTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM
J/C 17 (BEHIND RIGHT CENTER OF DASH, NEAR WINDSHIELD)
J/C 19 (UPPER RIGHT SIDE OF DASH)
J/C 21 (UPPER RIGHT SIDE OF DASH)
J/C 25 (UPPER RIGHT SIDE OF DASH)
J/C 26 (UPPER RIGHT SIDE OF DASH) J/C 11 (UPPER LEFT CENTER OF DASH)
J/C 3 (UPPER LEFT SIDE OF DASH)
J/C 4 (UPPER LEFT SIDE OF DASH)
J/C 6 (UPPER LEFT SIDE OF DASH)
J/C 9 (UPPER LEFT SIDE OF DASH)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LT BLU WIRE
MEMO
MEMORY SYSTEMS DOOR LOCKS SYSTEM
MIRR FUSE
PISW
PNK/BLK WIRE
PNK/BLU WIRE
POWER SEAT ECU (BELOW DRIVER'S SEAT)
PWRY RLCY LMRY TRY
RED WIRE
REMOTE CONTROL MIRROR ECU (LEFT SIDE OF DASH)
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
RLCL RRCL DURY DDRY ACY FRCL
RRCY STP DG TC
SIL
STARTING/CHARGING SYSTEM
TAIL HEAD KSW
TILT, TELESCOPIC ECU (LEFT SIDE OF DASH)
VIO/WHT WIRE
WIPER/WASHER SYSTEM
Go to component -> Body computer circuits -> FRRM PCY DMU PMU DKL PKL DML PML PKU DKU
