Lexus LX J100 (1998-2002) fr+ rl+ rr+ amp+ beep fr- fl- fl+ Wiring diagram
This page shows the only wiring diagram for the component.fr+ rl+ rr+ amp+ beep fr- fl- fl+, which is found in the car Lexus LX J100 (1998-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fr+ rl+ rr+ amp+ beep fr- fl- fl+ (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 AGND
1 2 3 4 5 6 7 8 9 10 11 12 13 FR+ FL+ PNK WIRE
AGND
AMP
ANT
BEEP
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
CIGAR FUSE
ENGINE ROOM J/B
FR+ RL+ RR+ AMP+ BEEP FR- FL- FL+
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
ILL
LEFT FRONT DOOR SPEAKER
LEFT KICK PANEL J/B
LEFT REAR DOOR SPEAKER
LEFT TWEETER
LT GRN WIRE
MUTE
MUTE ACCO +BO
NCA WIRE
ORG/ WIRE
PNK WIRE
POWER ANTENNA SYSTEM
RADIO FUSE
RADIO, PLAYER
RED WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT REAR DOOR SPEAKER
RIGHT TWEETER
RR (-) RL (-) FR (-) FL (-)
RR RL
SHIELD RL- RR-
SP-
SPI+
STEREO COMPONENT AMPLIFIER (UNDER RIGHT FRONT SEAT)
TELEPHONE TRANSCEIVER, SPEAKER RELAY (ABOVE RIGHT REAR WHEELWELL)
TLMT
VIO WIRE
WHT WIRE
WHT/GRN WIRE
WOOFER SPEAKER
YEL WIRE
Go to component -> Radio circuits -> FR+ RL+ RR+ AMP+ BEEP FR- FL- FL+
