Wiring diagram efi or ecd relay (1 of 2)
12 13 14 15 16 +B
ABS, BA, TRAC, VSC ECU (BEHIND LEFT SIDE OF DASH)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
CENTER AIR BAG SENSOR ASSEMBLY (UNDER FRONT OF CENTER CONSOLE)
CG SG
COMBINATION METER
D/G
DATA LINK CONNECTOR 1 (RIGHT INNER FENDER PANEL)
DATA LINK CONNECTOR 3 (BEHIND LEFT SIDE OF DASH)
EFI OR ECD RELAY
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
ENGINE ROOM J/B
HOT AT ALL TIMES
INSTRUMENT ECU (BEHIND CENTER OF DASH)
J/C 16 (UPPER RIGHT SIDE OF DASH)
J/C 21 (BEHIND RIGHT SIDE OF DASH)
LEFT KICK PANEL J/B
LT BLU WIRE
OBD FUSE
PNK/BLK WIRE
PNK/BLU WIRE
POWER SEAT ECU (BELOW DRIVER'S SEAT)
RED WIRE
RED/BLK WIRE
REMOTE CONTROL MIRROR ECU (BEHIND LEFT SIDE OF DASH)
SIL
SRS IND
SUSPENSION CONTROL ECU (BEHIND CENTER OF DASH)
TILT, TELESCOPIC ECU (BEHIND LEFT SIDE OF DASH)
VIO/RED WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Computer data lines -> EFI OR ECD RELAY
Wiring diagram efi or ecd relay (2 of 2)
A/T OIL TEMPERATURE SENSOR (TOP OF TRANSMISSION)
ACCEL POSITION SENSOR (TOP FRONT OF ENGINE)
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRAID
BRN WIRE
BRN/WHT WIRE
EFI OR ECD FUSE
EFI OR ECD RELAY
ENGINE COOLANT TEMPERATURE SENSOR (TOP FRONT OF ENGINE)
ENGINE ROOM J/B (ON LEFT INNER FENDER PANEL)
FP-
FPC
FUEL CONTROL SWITCH (BEHIND CENTER OF DASH)
FUEL PUMP (IN FUEL TANK)
FUEL PUMP CONTROL ECU (LEFT REAR OF CARGO AREA)
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HEATED OXYGEN SENSOR (BANK 1 SENSOR 1) (ON EXHAUST PIPE, LEFT REAR OF ENGINE)
HEATED OXYGEN SENSOR (BANK 2 SENSOR 1) (ON EXHAUST PIPE, RIGHT SIDE OF ENGINE)
HOT AT ALL TIMES
IGNITION SWITCH
INJECTOR 1
INJECTOR 2
INJECTOR 3
INJECTOR 4
INJECTOR 5
INJECTOR 6)
INJECTOR 7 (-)
INJECTOR 8 (-)
J/C 17 (BEHIND RIGHT CENTER OF DASH, NEAR WIND- SHIELD)
J/C 28 (BEHIND GLOVE BOX)
J/C 43 (BEHIND LEFT SIDE OF DASH)
LEFT KICK PANEL J/B
LEFT KICK PANEL J/B IGN FUSE
LOCK ON
LT BLU WIRE
P/N
PARK/NEUTRAL POSITION SWITCH (LEFT SIDE OF TRANSMISSION)
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
STARTING/CHARGING SYSTEM INSTRUMENT CLUSTER SYSTEM
THROTTLE POSITION SENSOR (ON THROTTLE BODY)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Wiring diagram engine performance 4.7ls (2 of 4) -> EFI OR ECD RELAY
