Lexus LX J100 (1998-2002) combination meter charge warning light Wiring diagram
This page shows the only wiring diagram for the component.combination meter charge warning light, which is found in the car Lexus LX J100 (1998-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram combination meter charge warning light (1 of 1)
ALT FUSIBLE LINK
ALT-S FUSIBLE LINK
BATTERY
BATTERY GROUND
BLK WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
COMBINATION METER CHARGE WARNING LIGHT
ENGINE ROOM J/B (ON LEFT INNER FENDER PANEL)
FUSE
FUSE FUSE
FUSIBLE LINK BLOCK (ON LEFT SIDE OF ENGINE COMPARTMENT, NEAR BATTERY)
GAUGE FUSE
GENERATOR
HEADLIGHTS, ELECTRONIC SUSPENSION SYSTEMS
IGN FUSE
IGNITION SWITCH
J/C 8 J/C 10 (2000-01) (1998-99) (LEFT SIDE OF DASH) (LEFT SIDE OF DASH)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LT LT
NCA WIRE
OFF
ORG/ WIRE
RED WIRE
RELAY
WHT WIRE
Go to component -> Charging circuit -> COMBINATION METER CHARGE WARNING LIGHT
