Lexus LX J100 (1998-2002) center airbag sensor assembly Wiring diagram
This page shows the only wiring diagram for the component.center airbag sensor assembly, which is found in the car Lexus LX J100 (1998-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram center airbag sensor assembly (1 of 1)
BRN WIRE
CENTER AIRBAG SENSOR ASSEMBLY
CENTER DIFFERENTIAL LOCK CONTROL MOTOR
CENTER DIFFERENTIAL LOCK DETECTION SWITCH
COMBINATION METER
CRUISE CONTROL SWITCH
DATA LINK CONNECTOR 1
DATA LINK CONNECTOR 3
DRIVER'S POWER SEAT CONTROL SWITCH
DRIVER'S POWER SEAT FRONT VERTICAL SENSOR
DRIVER'S POWER SEAT LUMBAR CONTROL SWITCH
DRIVER'S POWER SEAT REAR VERTICAL SENSOR DRIVER'S POWER SEAT SLIDE SENSOR
DRIVER'S POWER SEAT RECLINE SENSOR
DRIVER'S SEAT HEATER
ENGINE CONTROL MODULE
HEATED OXYGEN SENSOR BANK 1 SENSOR 1
HEATED OXYGEN SENSOR BANK 1 SENSOR 2
HEATED OXYGEN SENSOR BANK 2 SENSOR 1
HEATED OXYGEN SENSOR BANK 2 SENSOR 2
IGNITION COIL, IGNITER 1
IGNITION COIL, IGNITER 2
IGNITION COIL, IGNITER 3
IGNITION COIL, IGNITER 4
IGNITION COIL, IGNITER 5
IGNITION COIL, IGNITER 6
IGNITION COIL, IGNITER 7
IGNITION COIL, IGNITER 8
IGNITION NOISE FILTER
INSTRUMENT ECU
JUNCTION CONNECTOR J/C 17 (UPPER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 26 (UPPER RIGHT SIDE OF DASH)
LEFT BUCKLE SWITCH
LEFT KICK PANEL J/B (LEFT KICK PANEL)
LT BLU WIRE
NCA WIRE
POWER SEAT ECU
RIGHT KICK PANEL J/B (RIGHT KICK PANEL)
TO LEFT REAR POWER WINDOW SWITCH (DIAGRAM 3 OF 4)
TRANSFER NEUTRAL POSITION DETECTION SWITCH
TRANSPONDER KEY AMPLIFIER
VEHICLE SPEED SENSOR
WHT/BLK WIRE
Go to component -> Ground distribution circuit (1 of 4) -> CENTER AIRBAG SENSOR ASSEMBLY
