Lexus LX J100 (1998-2002) cds fan Wiring diagram
This page shows the only wiring diagram for the component.cds fan, which is found in the car Lexus LX J100 (1998-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cds fan (1 of 1)
11 14 (W/ NAVIGATION) (W/O NAVIGATION)
A/C CONDENSER FAN MOTOR (IN RIGHT FRONT OF ENGINE COMPT)
A/C CONDENSER FAN RELAY (ON LEFT FRONT OF ENGINE COMPT, NEAR HEADLIGHT)
A/C FUSE
A/C MAGNETIC CLUTCH, LOCK SENSOR (ON A/C COMPRESSOR)
A/C TRIPLE PRESSURE SWITCH (LEFT FRONT OF ENGINE COMPT, NEAR HEADLIGHT ASSEMBLY)
BLK WIRE
BLU WIRE
CDS FAN
CENTER ECU (BEHIND CENTER OF DASH) MGC
ENGINE ROOM J/B (ON LEFT INNER FENDER PANEL)
FUSE
HOT AT ALL TIMES
HOT IN ON OR START
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
MG CLT RELAY
RED WIRE
WHT WIRE
YEL WIRE
Go to component -> Cooling fan circuit -> CDS FAN
