Lexus LX J100 (1998-2002) bzr trly Wiring diagrams
This page contains all the electrical diagrams for the component. bzr trly, in which he is found in the car Lexus LX J100 (1998-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
bzr trly wiring diagram (1 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 GRD
1 7 2 11 9 4 BECU RLCY SIG DLRY TRY GRD
14 1 12 18 6 13 ACY RRCY DURY DISW PISW DDRY
20 11 6 10 7 14 3 9 5 8 4 KSW DKU DKL PKU PKL DCY PCY PML PMU DML DMU
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BZR TRLY
ENGINE ROOM J/B (ON LEFT INNER FENDER PANEL)
FUSE
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/BLU WIRE
HAZ- TRN FUSE
HOT AT ALL TIMES
INSTRUMENT ECU (BEHIND CENTER OF DASH)
JUNCTION CONNECTOR J/C 1 (LEFT END OF DASH)
JUNCTION CONNECTOR J/C 12 (LEFT SIDE OF DASH)
JUNCTION CONNECTOR J/C 14 (BEHIND LEFT CENTER OF DASH)
JUNCTION CONNECTOR J/C 15 (BEHIND LEFT CENTER OF DASH)
JUNCTION CONNECTOR J/C 16 (UPPER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 23 (UPPER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 24 (UPPER RIGHT END OF DASH)
JUNCTION CONNECTOR J/C 25 (UPPER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 3 (LEFT SIDE OF DASH)
JUNCTION CONNECTOR J/C 43 (BEHIND LEFT SIDE OF DASH)
KSW LSWD LSWP IG CTY
LEFT DOOR KEY LOCK/ UNLOCK SWITCH
LEFT DOOR LOCK CONTROL SWITCH (POWER WINDOW MASTER SWITCH)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LSWR
LT BLU WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RIGHT DOOR KEY LOCK/ UNLOCK SWITCH
RIGHT DOOR LOCK CONTROL SWITCH
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
WHT GRN/ WIRE
WHT WIRE
WHT/BLK WIRE
WIRELESS DOOR LOCK BUZZER (IN REAR OF LEFT FRONT FENDER)
WIRELESS DOOR LOCK ECU (BEHIND LEFT OF DASH)
Go to component -> Anti-theft circuit (1 of 3) -> BZR TRLY
