Lexus LX J100 (1998-2002) a/t indicator light switch Wiring diagrams
This page contains all the electrical diagrams for the component. a/t indicator light switch, in which he is found in the car Lexus LX J100 (1998-2002). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram a/t indicator light switch (1 of 2)
1 7 8 9 10 11 16 19 BATT +BM
7 8 9 21 24 29 30 31 M- M+
A/T INDICATOR LIGHT SWITCH
ACCEL POSITION SENSOR (TOP FRONT OF ENGINE)
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BRAID
BRAIDED
BRN WIRE
BRN/WHT WIRE
CL CL+
COMBINATION METER
CRUISE
CRUISE CONTROL SWITCH
CRUISE IND
DASH HARN, BEHIND COMBINATION METER)
EFI FUSE
EFI RELAY
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
ENGINE ROOM J/B
EOM CCS CMS
GAUGE FUSE
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START IGN FUSE
IGSW MREL SIL +B
J/C 11 (LEFT SIDE OF DASH)
J/C 14 (CENTER OF DASH)
J/C 16 (RIGHT SIDE OF DASH)
J/C 17 (RIGHT CENTER OF DASH)
J/C 18 (RIGHT CENTER OF DASH)
J/C 19 (RIGHT SIDE OF DASH)
J/C 21 J/C 21 (RIGHT SIDE (RIGHT SIDE OF DASH) OF DASH)
J/C 27 (BEHIND GLOVE BOX)
J/C 43 (LEFT SIDE OF DASH)
J/C 45 (RIGHT CENTER OF DASH)
LEFT KICK LEFT KICK PANEL J/B PANEL J/B
LEFT KICK PANEL J/B
LT BLU WIRE
OBD FUSE
ORG/ WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RES+
SET/ COAST
SIL
SPEEDO- METER
STOP FUSE
STOPLIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
STP PI SPD
THROTTLE CONTROL MOTOR (TOP LEFT FRONT OF ENGINE)
THROTTLE FUSE
VEHICLE SPEED SENSOR (COMBINATION METER) (LEFT SIDE OF TRANSMISSION)
VIO WIRE
VIO/RED WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WHT/BLK WIRE
WHT/BLK WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Cruise control circuit -> A/T INDICATOR LIGHT SWITCH
Wiring diagram a/t indicator light switch (2 of 2)
A/T INDICATOR LIGHT SWITCH
ABS IND.
ACTIVE TRAC IND
ANTI-LOCK BRAKE SYSTEM
BLU WIRE
BLU/WHT WIRE
BRAKE FLUID LEVEL WARNING SWITCH
BRN WIRE
COMBINATION METER
ENGINE ROOM J/B
FROM BRAKE INDICATOR (DIAGRAM 1 OF 2)
FROM COMBINATION
FUEL SENDER (IN FUEL TANK)
FUSE
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
J/C 1 (LEFT END OF DASH)
J/C 14 (UPPER CENTER OF DASH)
J/C 20 (UPPER RIGHT SIDE OF DASH)
J/C 23 (UPPER RIGHT SIDE OF DASH)
J/C 24 (UPPER RIGHT SIDE OF DASH)
J/C 26 (UPPER RIGHT SIDE OF DASH)
J/C 27 (RIGHT SIDE OF DASH)
LEFT FRONT DOOR COURTESY SWITCH
LEFT KICK PANEL J/B
LT BLU WIRE
NCA WIRE
OIL PRESSURE SENSOR
PARKING BRAKE SWITCH
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
SLIP IND
UNLOCK WARNING SWITCH
VSC OFF IND
VSC TRAC IND
WASHER LEVEL WARNING SWITCH (WASHER MOTOR)
WHT WIRE
WHT/BLK WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Instrument cluster circuit (2 of 2) -> A/T INDICATOR LIGHT SWITCH
