Lexus LX J100 (1998-2002) 1 11 18 6 15 10 rrcy rrcl disw pisw frcl rlcl Wiring diagram
This page shows the only wiring diagram for the component.1 11 18 6 15 10 rrcy rrcl disw pisw frcl rlcl, which is found in the car Lexus LX J100 (1998-2002). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1 11 18 6 15 10 rrcy rrcl disw pisw frcl rlcl (1 of 1)
1 11 18 6 15 10 RRCY RRCL DISW PISW FRCL RLCL
7 2 1 8 10 4 RLCY SIG BECU LMRY
BLK RED/ WIRE
BLU/WHT WIRE
BLU/YEL WIRE
GRD
GRN/BLK WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
INSTRUMENT ECU (BEHIND CENTER OF DASH)
JUNCTION CONNECTOR J/C 13 (BEHIND LEFT CENTER OF DASH)
JUNCTION CONNECTOR J/C 14 (LEFT CENTER OF DASH)
JUNCTION CONNECTOR J/C 17 (CENTER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 23 (UPPER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 24 (UPPER RIGHT END OF DASH)
JUNCTION CONNECTOR J/C 26 (UPPER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 6 (UPPER LEFT SIDE OF DASH)
KSW KYIL PKU DKU DKL PKL PCY DCY DML DMU PML PMU FRRM
LEFT DOOR KEY LOCK/ UNLOCK SWITCH
LEFT DOOR LOCK CONTROL SWITCH (POWER WINDOW MASTER SWITCH)
LEFT KICK PANEL J/B (AT LEFT KICK PANEL)
LT BLU WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RIGHT DOOR KEY LOCK/ UNLOCK SWITCH
RIGHT DOOR LOCK CONTROL SWITCH
RIGHT FRONT DOOR COURTESY LIGHT
RIGHT KICK PANEL J/B (AT RIGHT KICK PANEL)
RIGHT REAR DOOR COURTESY LIGHT
RIGHT SIDE STEP LIGHT
WHT/BLK WIRE
WIRELESS DOOR LOCK ECU (BEHIND LEFT OF DASH)
Go to component -> Courtesy lamps circuit (1 of 3) -> 1 11 18 6 15 10 RRCY RRCL DISW PISW FRCL RLCL
