Lexus LS V facelift (2021-2024) Charging circuit

ALT FUSE BATTERY BATTERY STATE SENSOR ASSEMBLY BLK WIRE BLK/WHT WIRE BLK/YEL WIRE CAN I/F COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM DISPLAY DRIVER SIDE J/B ENGINE ROOM J/B 1 FUSIBLE LINK BLOCK ASSEMBLY 2 GB (DRIVER DOOR SILL) GENERATOR ASSEMBLY GRY WIRE ICS FUSE LT BLU WIRE LUGGAGE ROOM J/B 1 LUGGAGE ROOM R/B 1 PPL PPL/GRN WIRE R/B FR FUSE R/B RR 1 FUSE RELAY ENERGIZED VIO WIRE WHT WIRE YEL WIRE
